Pride WS165W
4Ω
Woofer
| Nominal diameter | 6.5″ / 165 mm |
| Resonance | 49.7 Hz |
| Q factor | 0.45 |
| Sensitivity | 87.7 dB |
| Program Power | 180 W |
Discontinued
.jpg)
.jpg)
.jpg)
Specifications
- Sensitivity (1W, 1m, infinite baffle) SPL1W 87.7dB
Thiele & Small parameters
- Resonance frequency (free air) fS 49.7Hz
- Mechanical quality factor QMS 2.48
- Electrical quality factor QES 0.56
- Total quality factor QTS 0.45
Large signal parameters
- Power handling P 90W
- Program power Pmax 180W
Voice Coil
- Nominal impedance Z 4Ω
- DC resistance RE 3.5Ω
- Inductance (1kHz) LE 0.19mH
Magnet
- Force factor Bl 5.15N/A
- Motor constant Bl/√RE 2.76N/√W
Diaphragm
- Effective diameter 130mm
- Effective area SD 133cm²
- Moving mass MMS 13.6g
- Moving mass (without air load) MMD 12.5g
Suspensions
- Stiffness KMS 1.33N/mm
- Compliance CMS 752µm/N
- Equivalent volume to the compliance VAS 18.8L
- Mechanical resistance RMS 1.72N·s/m
Dimensions
- Nominal diameter 6.5″
- 165mm
- Overall diameter 166mm
- Volume occupied by the driver (estimated) 0.51L
