SEAS XM011-04 L22ROY24 Ω | |
|---|---|
| 8″ Woofer | |
| fS | 27 Hz |
| SD | 221 cm² |
| 20 - 2000 Hz | |
| QTS | 0.39 |
| xmax | 11.5 mm |
| SPL1W | 82.9 dB |
| Bl/√RE | 5.87 |
| Pmax | 500 W |
1298 results
Brand
Type
Available on
•
Nominal diameter
″
•
SensitivitySPL1W
dB
Thiele & Small parameters
•
Resonance frequencyfS
Hz
•
Mechanical quality factorQMS
•
Electrical quality factorQES
•
Total quality factorQTS
Large signal parameters
•
Maximum linear excursionxmax
mm
•
Air volume displaced at xmaxVD
cm³
•
Program powerPmax
W
Voice Coil & Magnet
•
Nominal impedanceZ
Ω
•
DC resistanceRE
Ω
•
Force factorBl
N/A
•
Motor constantBl/√RE
N/√W
•
InductanceLE
mH
•
VC Diameter
mm
Diaphragm
•
Effective diameter
mm
•
Effective areaSD
cm²
•
Moving massMMS
g
Suspensions
•
StiffnessKMS
N/mm
•
ComplianceCMS
µm/N
•
Equivalent volume to CMSVAS
L
•
Mechanical resistanceRMS
N·s/m
Dimensions
•
Overall size
mm
•
Baffle cutout diameter
mm
•
Overall depth
mm
•
Mounting depth
mm
•
Volume occupied
L
•
Net weight
kg
.jpg.webp)
SEAS E0121-04/06 C16NX001/X4 Ω | |
|---|---|
| 5.5″ Coaxial | |
| fS | 38 Hz |
| SD | 94 cm² |
| 20 - 30000 Hz | |
| QTS | 0.29 |
| xmax | 7 mm |
| SPL1W | 90 dB |
| Bl/√RE | 4.54 |
| Pmax | 250 W |
.jpg.webp)
PRV Audio 15W18008 Ω | |
|---|---|
| 15″ Woofer | |
| fS | 45.3 Hz |
| SD | 962 cm² |
| 48 - 2500 Hz | |
| QTS | 0.42 |
| xmax | 9.5 mm |
| SPL1W | 94.7 dB |
| Bl/√RE | 10.3 |
| Pmax | 1800 W |
.jpg.webp)
PRV Audio 10W1000-NDY-44 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 50.2 Hz |
| SD | 380 cm² |
| 50 - 5000 Hz | |
| QTS | 0.27 |
| xmax | 6.5 mm |
| SPL1W | 94.6 dB |
| Bl/√RE | 6.95 |
| Pmax | 1000 W |
.jpg.webp)
PRV Audio 10W1000-NDY8 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 62.1 Hz |
| SD | 380 cm² |
| 55 - 5500 Hz | |
| QTS | 0.40 |
| xmax | 6.5 mm |
| SPL1W | 94.9 dB |
| Bl/√RE | 5.64 |
| Pmax | 1000 W |
.jpg.webp)
Dayton Audio GF180-88 Ω | |
|---|---|
| 6.5″ Woofer | |
| fS | 53 Hz |
| SD | 130 cm² |
| 50 - 5000 Hz | |
| QTS | 0.50 |
| xmax | 4 mm |
| SPL1W | 87.6 dB |
| Bl/√RE | 2.79 |
| Pmax | 80 W |
.jpg.webp)
Wavecor WF275BD024 Ω | |
|---|---|
| 10.75″ Mid Bass | |
| fS | 28 Hz |
| SD | 312 cm² |
| 28 - 1500 Hz | |
| QTS | 0.45 |
| xmax | 9 mm |
| SPL1W | 88.1 dB |
| Bl/√RE | 4.53 |
| Pmax | 450 W |
.jpg.webp)
Wavecor WF275BD014 Ω | |
|---|---|
| 10.75″ Mid Bass | |
| fS | 27 Hz |
| SD | 312 cm² |
| 27 - 1500 Hz | |
| QTS | 0.37 |
| xmax | 9 mm |
| SPL1W | 88.3 dB |
| Bl/√RE | 5.05 |
| Pmax | 450 W |
.png.webp)
Wavecor WF166TU014 Ω | |
|---|---|
| 6.5″ Woofer | |
| fS | 50 Hz |
| SD | 139 cm² |
| 50 - 3500 Hz | |
| QTS | 0.45 |
| SPL1W | 89.3 dB |
| Bl/√RE | 2.91 |
| Pmax | 120 W |
.jpg.webp)
Wavecor WF165TU014 Ω | |
|---|---|
| 5.5″ Mid Bass | |
| fS | 56 Hz |
| SD | 136 cm² |
| 56 - 3000 Hz | |
| QTS | 0.84 |
| xmax | 3 mm |
| SPL1W | 86.2 dB |
| Bl/√RE | 2.48 |
| Pmax | 170 W |
.jpg.webp)
PHL audio 7321Nd8 Ω | |
|---|---|
| 18″ Subwoofer | |
| fS | 34 Hz |
| SD | 1250 cm² |
| 25 - 800 Hz | |
| QTS | 0.28 |
| xmax | 10 mm |
| SPL1W | 95.6 dB |
| Bl/√RE | 12.3 |
| Pmax | 2400 W |
.jpg.webp)
PHL audio 7221Nd8 Ω | |
|---|---|
| 18″ Subwoofer | |
| fS | 34 Hz |
| SD | 1250 cm² |
| 25 - 800 Hz | |
| QTS | 0.29 |
| xmax | 10 mm |
| SPL1W | 95.7 dB |
| Bl/√RE | 12.3 |
| Pmax | 2000 W |
.jpg.webp)
PHL audio 70818 Ω | |
|---|---|
| 18″ Subwoofer | |
| fS | 34 Hz |
| SD | 1282 cm² |
| 30 - 800 Hz | |
| QTS | 0.41 |
| xmax | 7.5 mm |
| SPL1W | 94.9 dB |
| Bl/√RE | 9.59 |
| Pmax | 1500 W |
.jpg.webp)
PHL audio 6301MNd8 Ω | |
|---|---|
| 15″ Subwoofer | |
| fS | 36 Hz |
| SD | 871 cm² |
| 30 - 1000 Hz | |
| QTS | 0.26 |
| xmax | 10.5 mm |
| SPL1W | 94.8 dB |
| Bl/√RE | 11 |
| Pmax | 2600 W |
.jpg.webp)
PHL audio 6201MNd8 Ω | |
|---|---|
| 15″ Subwoofer | |
| fS | 36 Hz |
| SD | 871 cm² |
| 30 - 1000 Hz | |
| QTS | 0.27 |
| xmax | 10.5 mm |
| SPL1W | 94.7 dB |
| Bl/√RE | 10.9 |
| Pmax | 2000 W |
.jpg.webp)
PHL audio 6121M-208 Ω | |
|---|---|
| 15″ Coaxial | |
| fS | 39 Hz |
| SD | 892 cm² |
| 35 - 1000 Hz | |
| QTS | 0.24 |
| xmax | 8.5 mm |
| SPL1W | 95.6 dB |
| Bl/√RE | 12.3 |
| Pmax | 1600 W |
.jpg.webp)
PHL audio 6031M8 Ω | |
|---|---|
| 15″ Subwoofer | |
| fS | 39 Hz |
| SD | 892 cm² |
| 35 - 1000 Hz | |
| QTS | 0.23 |
| xmax | 8.5 mm |
| SPL1W | 95.8 dB |
| Bl/√RE | 12.3 |
| Pmax | 2000 W |
.jpg.webp)
PHL audio 5550MNdS8 Ω | |
|---|---|
| 15″ Subwoofer | |
| fS | 42 Hz |
| SD | 871 cm² |
| 40 - 1500 Hz | |
| QTS | 0.31 |
| xmax | 11 mm |
| SPL1W | 95.4 dB |
| Bl/√RE | 10.2 |
| Pmax | 1000 W |
.jpg.webp)
PHL audio 5241MNdU-78 Ω | |
|---|---|
| 15″ Coaxial | |
| fS | 45 Hz |
| SD | 845 cm² |
| 50 - 2500 Hz | |
| QTS | 0.26 |
| xmax | 7.5 mm |
| SPL1W | 96.9 dB |
| Bl/√RE | 10.3 |
| Pmax | 800 W |
.jpg.webp)
PHL audio 5021M8 Ω | |
|---|---|
| 15″ Subwoofer | |
| fS | 32 Hz |
| SD | 892 cm² |
| 30 - 2000 Hz | |
| QTS | 0.30 |
| xmax | 7 mm |
| SPL1W | 93.6 dB |
| Bl/√RE | 10.1 |
| Pmax | 1000 W |
.jpg.webp)
PHL audio 5011MNdU8 Ω | |
|---|---|
| 15″ Subwoofer | |
| fS | 38 Hz |
| SD | 892 cm² |
| 40 - 2000 Hz | |
| QTS | 0.26 |
| xmax | 7.5 mm |
| SPL1W | 95.9 dB |
| Bl/√RE | 10 |
| Pmax | 1000 W |
.jpg.webp)
PHL audio 4330NdU8 Ω | |
|---|---|
| 12″ Subwoofer | |
| fS | 36 Hz |
| SD | 527 cm² |
| 30 - 1500 Hz | |
| QTS | 0.22 |
| xmax | 8 mm |
| SPL1W | 93.4 dB |
| Bl/√RE | 9.47 |
| Pmax | 1000 W |
.jpg.webp)
PHL audio 4310NdU8 Ω | |
|---|---|
| 12″ Subwoofer | |
| fS | 43 Hz |
| SD | 527 cm² |
| 30 - 1500 Hz | |
| QTS | 0.27 |
| xmax | 10 mm |
| SPL1W | 93.5 dB |
| Bl/√RE | 9.47 |
| Pmax | 1000 W |
.jpg.webp)
PHL audio 4031NdU8 Ω | |
|---|---|
| 12″ Subwoofer | |
| fS | 44 Hz |
| SD | 539 cm² |
| 40 - 2000 Hz | |
| QTS | 0.27 |
| xmax | 7.5 mm |
| SPL1W | 94.4 dB |
| Bl/√RE | 8.66 |
| Pmax | 1000 W |
.jpg.webp)
PHL audio 40318 Ω | |
|---|---|
| 12″ Subwoofer | |
| fS | 44 Hz |
| SD | 539 cm² |
| 40 - 2000 Hz | |
| QTS | 0.27 |
| xmax | 7.5 mm |
| SPL1W | 94.4 dB |
| Bl/√RE | 8.66 |
| Pmax | 1000 W |
.jpg.webp)
PHL audio 40218 Ω | |
|---|---|
| 12″ Subwoofer | |
| fS | 35 Hz |
| SD | 539 cm² |
| 30 - 2000 Hz | |
| QTS | 0.35 |
| xmax | 7.5 mm |
| SPL1W | 90.7 dB |
| Bl/√RE | 8.66 |
| Pmax | 1000 W |
.jpg.webp)
PHL audio 3920NdU-78 Ω | |
|---|---|
| 10″ Coaxial | |
| fS | 74 Hz |
| SD | 308 cm² |
| 60 - 2500 Hz | |
| QTS | 0.20 |
| xmax | 4.5 mm |
| SPL1W | 96.6 dB |
| Bl/√RE | 8.91 |
| Pmax | 900 W |
.jpg.webp)
PHL audio 3900-28 Ω | |
|---|---|
| 10″ Coaxial | |
| fS | 56 Hz |
| SD | 308 cm² |
| 50 - 2500 Hz | |
| QTS | 0.18 |
| xmax | 4.5 mm |
| SPL1W | 94.2 dB |
| Bl/√RE | 10.2 |
| Pmax | 800 W |
.jpg.webp)
PHL audio 3840NdU8 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 62 Hz |
| SD | 356 cm² |
| 60 - 3000 Hz | |
| QTS | 0.22 |
| xmax | 4.5 mm |
| SPL1W | 95.7 dB |
| Bl/√RE | 8.79 |
| Pmax | 500 W |
.jpg.webp)
PHL audio 38408 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 62 Hz |
| SD | 356 cm² |
| 60 - 3000 Hz | |
| QTS | 0.22 |
| xmax | 4.5 mm |
| SPL1W | 95.7 dB |
| Bl/√RE | 8.83 |
| Pmax | 500 W |
.jpg.webp)
PHL audio 3820NdU8 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 55 Hz |
| SD | 356 cm² |
| 50 - 2500 Hz | |
| QTS | 0.18 |
| xmax | 4.5 mm |
| SPL1W | 94.7 dB |
| Bl/√RE | 10.6 |
| Pmax | 800 W |
.jpg.webp)
PHL audio 38208 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 55 Hz |
| SD | 356 cm² |
| 50 - 2500 Hz | |
| QTS | 0.17 |
| xmax | 4.5 mm |
| SPL1W | 94.9 dB |
| Bl/√RE | 10.8 |
| Pmax | 800 W |
.jpg.webp)
PHL audio 3570NdS8 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 53 Hz |
| SD | 356 cm² |
| 40 - 3000 Hz | |
| QTS | 0.19 |
| xmax | 6.5 mm |
| SPL1W | 95 dB |
| Bl/√RE | 8.95 |
| Pmax | 600 W |
.jpg.webp)
PHL audio 3481-148 Ω | |
|---|---|
| 10″ Coaxial | |
| fS | 55 Hz |
| SD | 324 cm² |
| 40 - 3000 Hz | |
| QTS | 0.26 |
| xmax | 6 mm |
| SPL1W | 93.4 dB |
| Bl/√RE | 7.94 |
| Pmax | 500 W |
.jpg.webp)
PHL audio 3411NdU8 Ω | |
|---|---|
| 10″ Subwoofer | |
| fS | 47 Hz |
| SD | 356 cm² |
| 35 - 2000 Hz | |
| QTS | 0.29 |
| xmax | 8 mm |
| SPL1W | 92 dB |
| Bl/√RE | 7.69 |
| Pmax | 800 W |
.jpg.webp)
PHL audio 3411NdS8 Ω | |
|---|---|
| 10″ Subwoofer | |
| fS | 48 Hz |
| SD | 356 cm² |
| 35 - 2000 Hz | |
| QTS | 0.20 |
| xmax | 8 mm |
| SPL1W | 93.7 dB |
| Bl/√RE | 9.13 |
| Pmax | 800 W |
.jpg.webp)
PHL audio 34118 Ω | |
|---|---|
| 10″ Subwoofer | |
| fS | 47 Hz |
| SD | 356 cm² |
| 35 - 2000 Hz | |
| QTS | 0.23 |
| xmax | 8 mm |
| SPL1W | 93.3 dB |
| Bl/√RE | 8.54 |
| Pmax | 800 W |
.jpg.webp)
PHL audio 34008 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 53 Hz |
| SD | 356 cm² |
| 40 - 2000 Hz | |
| QTS | 0.28 |
| xmax | 6.5 mm |
| SPL1W | 93.2 dB |
| Bl/√RE | 7.94 |
| Pmax | 600 W |
.jpg.webp)
PHL audio 30208 Ω | |
|---|---|
| 10″ Woofer | |
| fS | 60 Hz |
| SD | 356 cm² |
| 50 - 4000 Hz | |
| QTS | 0.38 |
| xmax | 5 mm |
| SPL1W | 94.1 dB |
| Bl/√RE | 5.56 |
| Pmax | 400 W |
.jpg.webp)
PHL audio 3005NdU8 Ω | |
|---|---|
| 10″ Subwoofer | |
| fS | 53 Hz |
| SD | 356 cm² |
| 40 - 3000 Hz | |
| QTS | 0.46 |
| xmax | 9 mm |
| SPL1W | 91.3 dB |
| Bl/√RE | 5.81 |
| Pmax | 500 W |
