B&C Speaker 12BG100

Name: 12BG100
Brand: B&C Speaker

Subwoofer

12″ / 320 mm

Nominal diameter

39 Hz

Resonance

0.33

Q factor

90 dB

Sensitivity

± 10.5 mm

Linear excursion

2000 W

Program Power

Parts Express
: $$$
Amazon.com
: $$$
Sensitivity (1W, 1m, infinite baffle)
SPL_1W: 90.1; dB
Frequency response: 40 - 1000; Hz
Resonance frequency (free air)
f_S: 39.0; Hz
Mechanical quality factor
Q_MS: 6.80
Electrical quality factor
Q_ES: 0.35
Total quality factor
Q_TS: 0.33
Maximum linear excursion
x_max: 10.5; mm
Air volume displaced at x_max
V_D: 548; cm³
Power handling
P: 1000; W
Program power
P_max: 2000; W
Nominal impedance
Z: 8; Ω
DC resistance
R_E: 5.1; Ω
Inductance (1kHz)
L_E: 1.6; mH
VC Diameter: 100; mm
Winding height
H_VC: 27; mm
Winding material: Copper
Former material: Glass Fibre
Flux density
B: 1.15; T
Force factor
Bl: 23.0; N/A
Motor constant
Bl/√R_E: 10.2; N/√W
Air gap height
H_AG: 11; mm
Material: Neodymium Inside Slug
Effective diameter: 258; mm
Effective area
S_D: 522; cm²
Moving mass
M_MS: 152; g
Moving mass (without air load)
M_MD: 143.3; g
Material: Waterproof Both Sides
Stiffness
K_MS: 8.93; N/mm
Compliance
C_MS: 112; µm/N
Equivalent volume to the compliance
V_AS: 41; L
Mechanical resistance
R_MS: 5.48; N·s/m
Spider material: Silicone
Nominal diameter: 12; ″
: 320; mm
Overall diameter: 319; mm
Baffle cutout diameter: 281; mm
Overall depth: 137; mm
Flange thickness: 13; mm
Mounting depth: 124; mm
Volume occupied by the driver: 2.7; L
Net weight: 8.8; kg

Datasheet
