Eminence KAPPALITE 3015LF

Low frequency

Nominal diameter15″ / 381 mm
Resonance44 Hz
Q factor0.46
Sensitivity95.5 dB
Linear excursion± 9.6 mm
Program Power900 W
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
  • Sensitivity (1W, 1m, infinite baffle) SPL1W 95.5dB
  • Frequency response 40 - 1500Hz

Thiele & Small parameters

  • Resonance frequency (free air) fS 44Hz
  • Mechanical quality factor QMS 8.97
  • Electrical quality factor QES 0.48
  • Total quality factor QTS 0.46

Large signal parameters

  • Maximum linear excursion xmax 9.6mm
  • Maximum excursion before damage xlim 17mm
  • Air volume displaced at xmax VD 846cm³
  • Power handling P 450W
  • Program power Pmax 900W

Voice Coil

  • Nominal impedance Z 8Ω
  • DC resistance RE 5.5Ω
  • Inductance (1kHz) LE 0.93mH
  • VC Diameter 76.2mm
  • Winding material Copper
  • Former material Kapton

Magnet

  • Force factor Bl 17N/A
  • Motor constant Bl/√RE 7.25N/√W
  • Air gap height HAG 9.3mm
  • Weight 0.312kg
  • Material Neodymium

Diaphragm

  • Effective diameter 335mm
  • Effective area SD 881cm²
  • Moving mass MMS 93g
  • Moving mass (without air load) MMD 75g
  • Material Treated paper

Suspensions

  • Stiffness KMS 7.14N/mm
  • Compliance CMS 140µm/N
  • Equivalent volume to the compliance VAS 151L
  • Mechanical resistance RMS 2.87N·s/m
  • Surround material Cloth

Dimensions

  • Nominal diameter 15
  • 381mm
  • Overall diameter 389mm
  • Baffle cutout diameter 356mm
  • Overall depth 184mm
  • Volume occupied by the driver 2.55L
  • Net weight 3.901kg
  • Frame material Die-cast Aluminium
Eminence KAPPALITE 3015LF SPL & Impedance
