LaVoce FBASS15-20

Name: FBASS15-20
Brand: LaVoce

Bass Guitar Speaker

15″ / 380 mm

Nominal diameter

40 Hz

Resonance

0.53

Q factor

96 dB

Sensitivity

± 4.3 mm

Linear excursion

400 W

Program Power

Sensitivity (1W, 1m, infinite baffle)
SPL_1W: 96.1; dB
Frequency response: 40 - 4000; Hz
Resonance frequency (free air)
f_S: 40.0; Hz
Mechanical quality factor
Q_MS: 8.70
Electrical quality factor
Q_ES: 0.56
Total quality factor
Q_TS: 0.53
Maximum linear excursion
x_max: 4.3; mm
Maximum excursion before damage
x_lim: 8.4; mm
Air volume displaced at x_max
V_D: 368; cm³
Power handling
P: 200; W
Program power
P_max: 400; W
Nominal impedance
Z: 8; Ω
DC resistance
R_E: 5.3; Ω
Inductance (1kHz)
L_E: 0.7; mH
VC Diameter: 51; mm
Winding height
H_VC: 12.6; mm
Winding material: Copper
Former material: Glass fiber
Force factor
Bl: 12.8; N/A
Motor constant
Bl/√R_E: 5.56; N/√W
Air gap height
H_AG: 8.2; mm
Diameter: 140; mm
Height: 17; mm
Material: Ferrite
Effective diameter: 330; mm
Effective area
S_D: 855; cm²
Moving mass
M_MS: 70; g
Moving mass (without air load)
M_MD: 52.9; g
Material: Water Proof Treated Paper
Stiffness
K_MS: 4.35; N/mm
Compliance
C_MS: 230; µm/N
Equivalent volume to the compliance
V_AS: 234; L
Mechanical resistance
R_MS: 2.02; N·s/m
Surround material: Polycotton
Nominal diameter: 15; ″
: 380; mm
Volume occupied by the driver: 3.0; L
Net weight: 4.1; kg
Frame material: Steel

Datasheet

Export this driver to a simulation software:

LaVoce FBASS15-20

Bass Guitar Speaker

Thiele & Small parameters

Large signal parameters

Voice Coil

Magnet

Diaphragm

Suspensions

Dimensions

Export this driver to a simulation software:
