SB Acoustics SB34NRX75-16

16Ω

Woofer

Nominal diameter12″ / 305 mm
Resonance25 Hz
Q factor0.71
Sensitivity87.6 dB
Linear excursion± 11 mm
Program Power240 W
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
  • Sensitivity (1W, 1m, infinite baffle) SPL1W 87.6dB

Thiele & Small parameters

  • Resonance frequency (free air) fS 25Hz
  • Mechanical quality factor QMS 6.65
  • Electrical quality factor QES 0.80
  • Total quality factor QTS 0.71

Large signal parameters

  • Maximum linear excursion xmax 11mm
  • Air volume displaced at xmax VD 559cm³
  • Power handling P 120W
  • Program power Pmax 240W

Voice Coil

  • Nominal impedance Z 16Ω
  • DC resistance RE 14.0Ω
  • Inductance (1kHz) LE 3.2mH
  • VC Diameter 75.6mm
  • Winding height HVC 28mm
  • Winding material Copper Clad Aluminium

Magnet

  • Flux density B 0.9T
  • Force factor Bl 14.1N/A
  • Motor constant Bl/√RE 3.77N/√W
  • Air gap height HAG 6mm
  • Weight 2.1kg

Diaphragm

  • Effective diameter 254mm
  • Effective area SD 508cm²
  • Moving mass MMS 72g
  • Moving mass (without air load) MMD 63.9g
  • Material Norex

Suspensions

  • Stiffness KMS 1.79N/mm
  • Compliance CMS 560µm/N
  • Equivalent volume to the compliance VAS 205L
  • Mechanical resistance RMS 1.7N·s/m

Dimensions

  • Nominal diameter 12
  • 305mm
  • Volume occupied by the driver (estimated) 2.6L
  • Net weight 6.0kg
  • Frame material Cast aluminium
SB Acoustics SB34NRX75-16 SPL & Impedance
SB Acoustics SB34NRX75-16 Dimensions
