Tang Band W2-1625SA

Subwoofer

2″ / 51 mm
Nominal diameter
90 Hz
Resonance
0.31
Q factor
82 dB
Sensitivity
± 2 mm
Linear excursion
40 W
Program Power
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
Sensitivity (1W, 1m, infinite baffle)
SPL1W
81.6
dB
Frequency response
90 - 500
Hz

Thiele & Small parameters

Resonance frequency (free air)
fS
90.0
Hz
Mechanical quality factor
QMS
3.94
Electrical quality factor
QES
0.33
Total quality factor
QTS
0.31

Large signal parameters

Maximum linear excursion
xmax
2.0
mm
Air volume displaced at xmax
VD
3.0
cm³
Power handling
P
20
W
Program power
Pmax
40
W

Voice Coil

Nominal impedance
Z
8
Ω
DC resistance
RE
6.6
Ω
Inductance (1kHz)
LE
0.22
mH
VC Diameter
25
mm

Magnet

Force factor
Bl
5.16
N/A
Motor constant
Bl/√RE
2.01
N/√W
Air gap height
HAG
4
mm
Material
Neodymium

Diaphragm

Effective diameter
44
mm
Effective area
SD
15
cm²
Moving mass
MMS
2.3
g
Moving mass (without air load)
MMD
2.3
g
Material
Polypropylene

Suspensions

Stiffness
KMS
0.77
N/mm
Compliance
CMS
1295
µm/N
Equivalent volume to the compliance
VAS
0.31
L
Mechanical resistance
RMS
0.33
N·s/m
Surround material
Santoprene

Dimensions

Nominal diameter
2
51
mm
Net weight
0.21
kg
Tang Band W2-1625SA SPL & Impedance
Tang Band W2-1625SA Dimensions

Export this driver to a simulation software:

WinISDWinISDBasta!Basta!HornrespHornrespQSpeakersQSpeakersSpeakerSimSpeakerSimMfbLabsMfbLabsSpeakerbenchSpeakerbench

Similar subwoofers to Tang Band W2-1625SA

Dayton Audio ND64-4 Full-range
