41 results
Nominal diameter
SensitivitySPL1W
dB

Thiele & Small parameters

Resonance frequencyfS
Hz
Mechanical quality factorQMS
Electrical quality factorQES
Total quality factorQTS

Large signal parameters

Maximum linear excursionxmax
mm
Air volume displaced at xmaxVD
cm³
Program powerPmax
W

Voice Coil & Magnet

Nominal impedanceZ
Ω
DC resistanceRE
Ω
Force factorBl
N/A
Motor constantBl/√RE
N/√W
InductanceLE
mH
VC Diameter
mm

Diaphragm

Effective diameter
mm
Effective areaSD
cm²
Moving massMMS
g

Suspensions

StiffnessKMS
N/mm
ComplianceCMS
µm/N
Equivalent volume to CMSVAS
L
Mechanical resistanceRMS
N·s/m

Dimensions

Overall size
mm
Baffle cutout diameter
mm
Overall depth
mm
Mounting depth
mm
Volume occupied
L
Net weight
kg
Tang Band W8-1722B Woofer
8Woofer
fS
35 Hz
SD
220 cm²
35 - 8000 Hz
QTS
0.51
xmax
9.0 mm
SPL1W
88 dB
Bl/√RE
3.29
Pmax
120 W
mivoc XAW 210 HC Woofer
8Woofer
fS
32 Hz
SD
209 cm²
32 - 1000 Hz
QTS
0.27
xmax
7.8 mm
SPL1W
88 dB
Bl/√RE
5.72
Pmax
300 W
mivoc AW 2000 Woofer
8Woofer
fS
30 Hz
SD
214 cm²
30 - 500 Hz
QTS
0.29
xmax
6.5 mm
SPL1W
87 dB
Bl/√RE
5.37
Pmax
300 W
Tang Band W8-2096B Woofer
8Woofer
fS
32 Hz
SD
220 cm²
32 - 5000 Hz
QTS
0.32
xmax
8.5 mm
SPL1W
88 dB
Bl/√RE
4.19
Pmax
160 W
Tang Band W8-2096 Woofer
8Woofer
fS
35 Hz
SD
220 cm²
35 - 6000 Hz
QTS
0.39
xmax
8.5 mm
SPL1W
87 dB
Bl/√RE
4.1
Pmax
160 W
Tang Band W6-1721 Woofer
6Woofer
fS
40 Hz
SD
140 cm²
40 - 5000 Hz
QTS
0.43
xmax
8.0 mm
SPL1W
88 dB
Bl/√RE
2.78
Pmax
100 W
Peerless NE225W-04 Woofer
8Woofer
fS
37 Hz
SD
227 cm²
30 - 1000 Hz
QTS
0.37
xmax
10.3 mm
SPL1W
88 dB
Bl/√RE
4.86
Pmax
250 W
Morel TiW 634Nd Woofer
6Woofer
fS
34 Hz
SD
119 cm²
QTS
0.29
xmax
5.5 mm
SPL1W
86 dB
Bl/√RE
3.39
Pmax
300 W
Morel TiCW 634Nd Woofer
6Woofer
fS
34 Hz
SD
119 cm²
QTS
0.29
xmax
5.5 mm
SPL1W
87 dB
Bl/√RE
3.43
Pmax
300 W
Ciare HWG160 Woofer
6.5Woofer
fS
39 Hz
SD
141 cm²
QTS
0.33
xmax
6.5 mm
SPL1W
89 dB
Bl/√RE
3.41
Pmax
260 W
Ciare HWB200 Woofer
8Woofer
fS
32 Hz
SD
224 cm²
QTS
0.38
xmax
7.0 mm
SPL1W
89 dB
Bl/√RE
3.96
Pmax
260 W
Ciare CW202 Woofer
8Woofer
fS
40 Hz
SD
222 cm²
QTS
0.41
xmax
6.5 mm
SPL1W
89 dB
Bl/√RE
3.31
Pmax
240 W
Ciare CW162 Woofer
6.5Woofer
fS
40 Hz
SD
133 cm²
QTS
0.21
xmax
7.0 mm
SPL1W
89 dB
Bl/√RE
4.26
Pmax
200 W
