Celestion BN10-300X (4)

Bass Guitar Speaker

10″ / 254 mm
Nominal diameter
64 Hz
Resonance
0.43
Q factor
93 dB
Sensitivity
± 4 mm
Linear excursion
600 W
Program Power
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
Sensitivity (1W, 1m, infinite baffle)
SPL1W
93.3
dB
Frequency response
40 - 2500
Hz

Thiele & Small parameters

Resonance frequency (free air)
fS
64.2
Hz
Mechanical quality factor
QMS
3.33
Electrical quality factor
QES
0.50
Total quality factor
QTS
0.43

Large signal parameters

Maximum linear excursion
xmax
4.0
mm
Air volume displaced at xmax
VD
139
cm³
Power handling
P
300
W
Program power
Pmax
600
W

Voice Coil

Nominal impedance
Z
4
Ω
DC resistance
RE
3.0
Ω
Inductance (1kHz)
LE
0.32
mH
VC Diameter
64
mm
Winding height
HVC
16
mm
Winding material
Copper
Former material
Polyimide

Magnet

Force factor
Bl
9.39
N/A
Motor constant
Bl/√RE
5.39
N/√W
Air gap height
HAG
8
mm
Height
37
mm
Material
Neodymium

Diaphragm

Effective diameter
210
mm
Effective area
SD
346
cm²
Moving mass
MMS
35.8
g
Moving mass (without air load)
MMD
31.2
g
Material
Kevlar loaded paper

Suspensions

Stiffness
KMS
5.88
N/mm
Compliance
CMS
170
µm/N
Equivalent volume to the compliance
VAS
29.2
L
Mechanical resistance
RMS
4.34
N·s/m
Surround material
Cloth-sealed

Dimensions

Nominal diameter
10
254
mm
Overall diameter
256
mm
Baffle cutout diameter
229
mm
Overall depth
112
mm
Volume occupied by the driver (estimated)
0.85
L
Net weight
1.6
kg
Celestion BN10-300X (4) SPL & Impedance
