Goldwood GW-412D

Woofer

12″ / 305 mm
Nominal diameter
38 Hz
Resonance
0.73
Q factor
92 dB
Sensitivity
± 2.5 mm
Linear excursion
260 W
Program Power
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply

Available on (affiliate link)

Parts Express
$$

Specifications

Sensitivity (1W, 1m, infinite baffle)
SPL1W
91.5
dB
Frequency response
33 - 2000
Hz

Thiele & Small parameters

Resonance frequency (free air)
fS
37.8
Hz
Mechanical quality factor
QMS
5.76
Electrical quality factor
QES
0.83
Total quality factor
QTS
0.73

Large signal parameters

Maximum linear excursion
xmax
2.5
mm
Air volume displaced at xmax
VD
132
cm³
Power handling
P
130
W
Program power
Pmax
260
W

Voice Coil

Nominal impedance
Z
2 x 8
Ω
DC resistance (in series)
RE
13.6
Ω
Inductance (1kHz, in series)
LE
0.2
mH
VC Diameter
38
mm
Winding material
Aluminum

Magnet

Force factor (in series)
Bl
15.76
N/A
Motor constant
Bl/√RE
4.27
N/√W
Weight
0.85
kg

Diaphragm

Effective diameter
259
mm
Effective area
SD
526
cm²
Moving mass
MMS
63.5
g
Moving mass (without air load)
MMD
55.1
g
Material
Poly

Suspensions

Stiffness
KMS
3.58
N/mm
Compliance
CMS
279
µm/N
Equivalent volume to the compliance
VAS
109
L
Mechanical resistance
RMS
2.62
N·s/m
Surround material
Rolled Foam

Dimensions

Nominal diameter
12
305
mm
Overall diameter
305
mm
Baffle cutout diameter
279
mm
Mounting depth
132
mm
Volume occupied by the driver (estimated)
0.98
L
Net weight
2.359
kg
Frame material
Stamped Steel
Goldwood GW-412D SPL & Impedance
