MONACOR SP-380PA

Woofer

Nominal diameter15″ / 384 mm
Resonance38 Hz
Q factor0.54
Sensitivity93.3 dB
Linear excursion± 3.3 mm
Program Power500 W
Ω°0102030405060101001 00010 000-180-120-60060120180Electrical ImpedanceElectrical Phase
mm05101520101001 00010 000Diaphragm ExcursionMaximum Linear Excursion
m/s0246810101001 00010 000Diaphragm Velocity
dB60708090100110120101001 00010 000SPL (1W, 1m, on axis)Maximum SPL
°-180-120-60060120180101001 00010 000Acoustical phase (1m, on axis)
ms051015202530101001 00010 000Group Delay (1m, on axis)
00.51-205101520Step response
-1-0.500.51-2010203040Response to a tone burst of Hz with cycles
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
  • Sensitivity (1W, 1m, infinite baffle) SPL1W 93.3dB
  • Frequency response 38 - 3500Hz

Thiele & Small parameters

  • Resonance frequency (free air) fS 38Hz
  • Mechanical quality factor QMS 3.68
  • Electrical quality factor QES 0.64
  • Total quality factor QTS 0.54

Large signal parameters

  • Maximum linear excursion xmax 3.3mm
  • Air volume displaced at xmax VD 275cm³
  • Power handling P 250W
  • Program power Pmax 500W

Voice Coil

  • Nominal impedance Z 8Ω
  • DC resistance RE 5.9Ω
  • Inductance (1kHz) LE 0.9mH
  • VC Diameter 50mm
  • Winding material Aluminium

Magnet

  • Force factor Bl 14.5N/A
  • Motor constant Bl/√RE 5.97N/√W
  • Diameter 156mm
  • Weight 1.4kg

Diaphragm

  • Effective diameter 328mm
  • Effective area SD 845cm²
  • Moving mass MMS 95g
  • Moving mass (without air load) MMD 77.9g

Suspensions

  • Stiffness KMS 5.26N/mm
  • Compliance CMS 190µm/N
  • Equivalent volume to the compliance VAS 185L
  • Mechanical resistance RMS 6.16N·s/m

Dimensions

  • Nominal diameter 15
  • 384mm
  • Overall diameter 384mm
  • Baffle cutout diameter 353mm
  • Overall depth 149mm
  • Flange thickness 0mm
  • Mounting depth 149mm
  • Volume occupied by the driver (estimated) 2.7L
  • Net weight 4.7kg
MONACOR SP-380PA SPL & Impedance
MONACOR SP-380PA Dimensions
