MTX Audio T612-22
2x2Ω
2x4ΩSubwoofer
| Nominal diameter | 12″ / 300 mm |
| Resonance | 31.2 Hz |
| Q factor | 0.55 |
| Sensitivity | 86.9 dB |
| Linear excursion | ± 16 mm |
| Program Power | 1200 W |
Discontinued
.jpg)
.jpg)
.jpg)
Specifications
- Sensitivity (1W, 1m, infinite baffle) SPL1W 86.9dB
- Frequency response 31 - 200Hz
Thiele & Small parameters
- Resonance frequency (free air) fS 31.2Hz
- Mechanical quality factor QMS 4.66
- Electrical quality factor QES 0.63
- Total quality factor QTS 0.55
Large signal parameters
- Maximum linear excursion (one way) xmax 16mm
- Air volume displaced at xmax VD 850cm³
- Power handling P 400W
- Program power Pmax 1200W
Voice Coil
- Nominal impedance Z 2 x 2Ω
- DC resistance (in series) RE 3.5Ω
- Inductance (1kHz, in series, estimated) LE 2.85mH
Magnet
- Force factor (in series) Bl 18.8N/A
- Motor constant Bl/√RE 10.1N/√W
Diaphragm
- Effective diameter 260mm
- Effective area SD 531cm²
- Moving mass MMS 227g
- Moving mass (without air load) MMD 219g
Suspensions
- Stiffness KMS 10.3N/mm
- Compliance CMS 97µm/N
- Equivalent volume to the compliance VAS 31.6L
- Mechanical resistance RMS 9.57N·s/m
Dimensions
- Nominal diameter 12″
- 300mm
- Volume occupied by the driver (estimated) 2.3L
