Peerless FLT-100N38AR02-08
8Ω
Shallow Woofer
| Nominal diameter | 4″ / 102 mm |
| Resonance | 113 Hz |
| Q factor | 0.81 |
| Sensitivity | 82.3 dB |
| Linear excursion | ± 2.5 mm |
| Program Power | 50 W |
Discontinued
.jpg)
.jpg)
Specifications
- Sensitivity (1W, 1m, infinite baffle) SPL1W 82.3dB
Thiele & Small parameters
- Resonance frequency (free air) fS 113Hz
- Mechanical quality factor QMS 3.65
- Electrical quality factor QES 1.04
- Total quality factor QTS 0.81
Large signal parameters
- Maximum linear excursion (one way) xmax 2.5mm
- Air volume displaced at xmax VD 16cm³
- Power handling P 25W
- Program power Pmax 50W
Voice Coil
- Nominal impedance Z 8Ω
- DC resistance RE 6.7Ω
- Inductance (1kHz) LE 0.52mH
- VC Diameter 38.4mm
- Former material Aluminium
Magnet
- Force factor Bl 8.55N/A
- Motor constant Bl/√RE 3.29N/√W
- Air gap height HAG 5mm
Diaphragm
- Effective diameter 90mm
- Effective area SD 63.6cm²
- Moving mass MMS 15.9g
- Moving mass (without air load) MMD 15.6g
Suspensions
- Stiffness KMS 8.02N/mm
- Compliance CMS 125µm/N
- Equivalent volume to the compliance VAS 0.71L
- Mechanical resistance RMS 3.09N·s/m
Dimensions
- Nominal diameter 4″
- 102mm
- Volume occupied by the driver (estimated) 0.13L
- Net weight 0.34kg
.png)
.png)
Export this driver to a simulation software:
Closed Box Simulator·
Speakerbench
WinISD
Basta!
Hornresp
QSpeakers
SpeakerSim
