Skar Audio IX-12 D4

2x2Ω
2x4Ω

Subwoofer

12″ / 314 mm
Nominal diameter
35 Hz
Resonance
0.62
Q factor
88 dB
Sensitivity
± 7 mm
Linear excursion
500 W
Program Power
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
Sensitivity (1W, 1m, infinite baffle)
SPL1W
88.1
dB

Thiele & Small parameters

Resonance frequency (free air)
fS
35.1
Hz
Mechanical quality factor
QMS
5.90
Electrical quality factor
QES
0.69
Total quality factor
QTS
0.62

Large signal parameters

Maximum linear excursion
xmax
7.0
mm
Air volume displaced at xmax
VD
357
cm³
Power handling
P
250
W
Program power
Pmax
500
W

Voice Coil

Nominal impedance
Z
2 x 4
Ω
DC resistance (in series)
RE
6.1
Ω
Inductance (1kHz, in series, estimated)
LE
1.5
mH
VC Diameter
51
mm
Winding material
Copper

Magnet

Force factor (in series)
Bl
14.8
N/A
Motor constant
Bl/√RE
5.99
N/√W
Diameter
140
mm

Diaphragm

Effective diameter
255
mm
Effective area
SD
510
cm²
Moving mass
MMS
111.7
g
Moving mass (without air load)
MMD
103.3
g
Material
Pressed Paper

Suspensions

Stiffness
KMS
5.44
N/mm
Compliance
CMS
184
µm/N
Equivalent volume to the compliance
VAS
67.8
L
Mechanical resistance
RMS
4.18
N·s/m
Surround material
Foam

Dimensions

Nominal diameter
12
314
mm
Overall diameter
314
mm
Baffle cutout diameter
284
mm
Overall depth
155
mm
Flange thickness
21
mm
Mounting depth
134
mm
Volume occupied by the driver (estimated)
2.7
L
