Tang Band W8-670Q

T
Q

Subwoofer

Nominal diameter8″ / 203 mm
Resonance38 Hz
Q factor0.46
Sensitivity85.8 dB
Linear excursion± 7 mm
Program Power140 W
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
  • Sensitivity (1W, 1m, infinite baffle) SPL1W 85.8dB
  • Frequency response 38 - 500Hz

Thiele & Small parameters

  • Resonance frequency (free air) fS 38Hz
  • Mechanical quality factor QMS 5.35
  • Electrical quality factor QES 0.51
  • Total quality factor QTS 0.46

Large signal parameters

  • Maximum linear excursion xmax 7mm
  • Air volume displaced at xmax VD 154cm³
  • Power handling P 70W
  • Program power Pmax 140W

Voice Coil

  • Nominal impedance Z 8Ω
  • DC resistance RE 6.5Ω
  • Inductance (1kHz) LE 0.961mH
  • VC Diameter 38.5mm

Magnet

  • Force factor Bl 12.3N/A
  • Motor constant Bl/√RE 4.81N/√W
  • Air gap height HAG 8mm
  • Material Ferrite

Diaphragm

  • Effective diameter 167mm
  • Effective area SD 220cm²
  • Moving mass MMS 49.9g
  • Moving mass (without air load) MMD 47.6g
  • Material Paper

Suspensions

  • Stiffness KMS 2.76N/mm
  • Compliance CMS 363µm/N
  • Equivalent volume to the compliance VAS 25L
  • Mechanical resistance RMS 2.23N·s/m
  • Surround material Rubber

Dimensions

  • Nominal diameter 8
  • 203mm
  • Volume occupied by the driver (estimated) 1.3L
  • Net weight 3.08kg
Tang Band W8-670Q SPL & Impedance
Tang Band W8-670Q Dimensions
