Celestion BN15-400X

Bass Guitar Speaker

Nominal diameter15″ / 381 mm
Resonance35.1 Hz
Q factor0.53
Sensitivity93.7 dB
Linear excursion± 4 mm
Program Power800 W
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
  • Sensitivity (1W, 1m, infinite baffle) SPL1W 93.7dB
  • Frequency response 38 - 3000Hz

Thiele & Small parameters

  • Resonance frequency (free air) fS 35.1Hz
  • Mechanical quality factor QMS 5.07
  • Electrical quality factor QES 0.59
  • Total quality factor QTS 0.53

Large signal parameters

  • Maximum linear excursion xmax 4mm
  • Air volume displaced at xmax VD 342cm³
  • Power handling P 400W
  • Program power Pmax 800W

Voice Coil

  • Nominal impedance Z 8Ω
  • DC resistance RE 5.2Ω
  • Inductance (1kHz) LE 1.08mH
  • VC Diameter 76.2mm
  • Winding height HVC 18mm
  • Winding material Copper
  • Former material Polyimide

Magnet

  • Force factor Bl 12.9N/A
  • Motor constant Bl/√RE 5.66N/√W
  • Air gap height HAG 10mm
  • Height 40mm
  • Material Neodymium

Diaphragm

  • Effective diameter 330mm
  • Effective area SD 855cm²
  • Moving mass MMS 84g
  • Moving mass (without air load) MMD 66.7g
  • Material Kevlar loaded paper

Suspensions

  • Stiffness KMS 4.1N/mm
  • Compliance CMS 244µm/N
  • Equivalent volume to the compliance VAS 253L
  • Mechanical resistance RMS 3.66N·s/m
  • Surround material Cloth-sealed

Dimensions

  • Nominal diameter 15
  • 381mm
  • Overall diameter 385mm
  • Baffle cutout diameter 351mm
  • Overall depth 152mm
  • Volume occupied by the driver (estimated) 1.8L
  • Net weight 2.6kg
