Ciare HW162
Woofer
6.5″ / 165 mm
Nominal diameter
44 Hz
Resonance
0.33
Q factor
89 dB
Sensitivity
± 4.5 mm
Linear excursion
180 W
Program Power
.jpg)
- Sensitivity (1W, 1m, infinite baffle)
- SPL1W
- 88.9
- dB
- Resonance frequency (free air)
- fS
- 44.0
- Hz
- Mechanical quality factor
- QMS
- 2.29
- Electrical quality factor
- QES
- 0.39
- Total quality factor
- QTS
- 0.33
- Maximum linear excursion
- xmax
- 4.5
- mm
- Air volume displaced at xmax
- VD
- 60
- cm³
- Power handling
- P
- 80
- W
- Program power
- Pmax
- 180
- W
- Nominal impedance
- Z
- 8
- Ω
- DC resistance
- RE
- 6.1
- Ω
- Inductance (1kHz)
- LE
- 0.65
- mH
- VC Diameter
- 32
- mm
- Winding height
- HVC
- 12
- mm
- Former material
- Aluminum
- Force factor
- Bl
- 7.5
- N/A
- Motor constant
- Bl/√RE
- 3.04
- N/√W
- Air gap height
- HAG
- 6
- mm
- Effective diameter
- 130
- mm
- Effective area
- SD
- 133
- cm²
- Moving mass
- MMS
- 13
- g
- Moving mass (without air load)
- MMD
- 11.8
- g
- Material
- Polypropylene
- Stiffness
- KMS
- 1.0
- N/mm
- Compliance
- CMS
- 1000
- µm/N
- Equivalent volume to the compliance
- VAS
- 24.8
- L
- Mechanical resistance
- RMS
- 1.57
- N·s/m
- Surround material
- Rubber
- Nominal diameter
- 6.5
- ″
- 165
- mm
- Overall diameter
- 169
- mm
- Baffle cutout diameter
- 142
- mm
- Overall depth
- 79
- mm
- Flange thickness
- 8
- mm
- Mounting depth
- 71
- mm
- Volume occupied by the driver (estimated)
- 0.49
- L
- Net weight
- 1.43
- kg
- Frame material
- Steel
Thiele & Small parameters
Large signal parameters
Voice Coil
Magnet
Diaphragm
Suspensions
Dimensions
.png)
.png)
Export this driver to a simulation software:
WinISD
Basta!
Hornresp
QSpeakers
SpeakerSim
