KICKER CompC 44CWCS104
2x4Ω
4Ω
Subwoofer
10″ / 250 mm
Nominal diameter
36 Hz
Resonance
0.59
Q factor
87 dB
Sensitivity
± 13.15 mm
Linear excursion
500 W
Program Power
.jpg)
.jpg)
.jpg)
- Sensitivity (1W, 1m, infinite baffle)
- SPL1W
- 86.8
- dB
- Frequency response
- 30 - 500
- Hz
- Resonance frequency (free air)
- fS
- 35.5
- Hz
- Mechanical quality factor
- QMS
- 20.96
- Electrical quality factor
- QES
- 0.61
- Total quality factor
- QTS
- 0.59
- Maximum linear excursion
- xmax
- 13.15
- mm
- Air volume displaced at xmax
- VD
- 473
- cm³
- Power handling
- P
- 250
- W
- Program power
- Pmax
- 500
- W
- Nominal impedance
- Z
- 4
- Ω
- DC resistance
- RE
- 3.8
- Ω
- Inductance (1kHz)
- LE
- 2.57
- mH
- Force factor
- Bl
- 11.7
- N/A
- Motor constant
- Bl/√RE
- 5.98
- N/√W
- Effective diameter
- 214
- mm
- Effective area
- SD
- 360
- cm²
- Moving mass
- MMS
- 97.4
- g
- Moving mass (without air load)
- MMD
- 92.7
- g
- Stiffness
- KMS
- 4.85
- N/mm
- Compliance
- CMS
- 207
- µm/N
- Equivalent volume to the compliance
- VAS
- 37.9
- L
- Mechanical resistance
- RMS
- 1.0365
- N·s/m
- Nominal diameter
- 10
- ″
- 250
- mm
- Baffle cutout diameter
- 231
- mm
- Mounting depth
- 122
- mm
- Volume occupied by the driver (estimated)
- 1.5
- L
Thiele & Small parameters
Large signal parameters
Voice Coil
Magnet
Diaphragm
Suspensions
Dimensions
