SB Acoustics SB15NRXC30-8

• Sensitivity (1W, 1m, infinite baffle) SPL1W 86.9dB

Thiele & Small parameters

• Resonance frequency (free air) fS 38Hz
• Mechanical quality factor QMS 4.80
• Electrical quality factor QES 0.35
• Total quality factor QTS 0.33

Large signal parameters

• Maximum linear excursion xmax 5mm
• Air volume displaced at xmax VD 41cm³
• Power handling P 50W
• Program power Pmax 100W

Voice Coil

• Nominal impedance Z 8Ω
• DC resistance RE 5.7Ω
• Inductance (1kHz) LE 0.14mH
• VC Diameter 30.5mm
• Winding height HVC 15mm

Magnet

• Flux density B 1T
• Force factor Bl 5.6N/A
• Motor constant Bl/√RE 2.35N/√W
• Air gap height HAG 5mm
• Weight 0.54kg

Diaphragm

• Effective diameter 102mm
• Effective area SD 82cm²
• Moving mass MMS 8.1g
• Moving mass (without air load) MMD 7.6g

Suspensions

• Stiffness KMS 0.461N/mm
• Compliance CMS 2170µm/N
• Equivalent volume to the compliance VAS 20.7L
• Mechanical resistance RMS 0.4N·s/m

Dimensions

• Nominal diameter 5″
• 127mm
• Volume occupied by the driver (estimated) 0.6L
• Net weight 1.48kg
