28 results
Nominal diameter
SensitivitySPL1W
dB

Thiele & Small parameters

Resonance frequencyfS
Hz
Mechanical quality factorQMS
Electrical quality factorQES
Total quality factorQTS

Large signal parameters

Maximum linear excursionxmax
mm
Air volume displaced at xmaxVD
cm³
Program powerPmax
W

Voice Coil & Magnet

Nominal impedanceZ
Ω
DC resistanceRE
Ω
Force factorBl
N/A
Motor constantBl/√RE
N/√W
InductanceLE
mH
VC Diameter
mm

Diaphragm

Effective diameter
mm
Effective areaSD
cm²
Moving massMMS
g

Suspensions

StiffnessKMS
N/mm
ComplianceCMS
µm/N
Equivalent volume to CMSVAS
L
Mechanical resistanceRMS
N·s/m

Dimensions

Overall size
mm
Baffle cutout diameter
mm
Overall depth
mm
Mounting depth
mm
Volume occupied
L
Net weight
kg
VISATON HX 10 - 4 Ohm 2 Way

VISATON HX 10 - 4 Ohm

4 Ω
4 2 Way
fS70 Hz
SD55 cm²
50 - 22000 Hz
QTS0.50
xmax1.5 mm
SPL1W86.8 dB
Bl/√RE1.88
Pmax60 W
Hertz MPX 165.3 PRO 2 Way

Hertz MPX 165.3 PRO

4 Ω
6.5 2 Way
fS90 Hz
SD137 cm²
45 - 21500 Hz
QTS0.88
xmax3 mm
SPL1W87.5 dB
Bl/√RE3.29
Pmax200 W
Hertz HMX 8 S LD 2 Way

Hertz HMX 8 S LD

4 Ω
8 2 Way
fS50 Hz
SD237 cm²
45 - 25000 Hz
QTS0.58
xmax4.5 mm
SPL1W89.4 dB
Bl/√RE3.75
Pmax200 W
Hertz HMX 8 S 2 Way

Hertz HMX 8 S

4 Ω
8 2 Way
fS50 Hz
SD237 cm²
45 - 25000 Hz
QTS0.58
xmax4.5 mm
SPL1W89.4 dB
Bl/√RE3.75
Pmax200 W
Hertz HMX 8 LD 2 Way

Hertz HMX 8 LD

4 Ω
8 2 Way
fS50 Hz
SD237 cm²
45 - 25000 Hz
QTS0.58
xmax4.5 mm
SPL1W89.4 dB
Bl/√RE3.75
Pmax200 W
Hertz HMX 8 2 Way

Hertz HMX 8

4 Ω
8 2 Way
fS50 Hz
SD237 cm²
45 - 25000 Hz
QTS0.58
xmax4.5 mm
SPL1W89.4 dB
Bl/√RE3.75
Pmax200 W
Hertz HMX 6.5 S LD 2 Way

Hertz HMX 6.5 S LD

4 Ω
6.5 2 Way
fS65 Hz
SD125 cm²
50 - 25000 Hz
QTS0.70
xmax3.7 mm
SPL1W87.5 dB
Bl/√RE2.78
Pmax150 W
Hertz HMX 6.5 S 2 Way

Hertz HMX 6.5 S

4 Ω
6.5 2 Way
fS65 Hz
SD125 cm²
50 - 25000 Hz
QTS0.70
xmax3.7 mm
SPL1W87.5 dB
Bl/√RE2.78
Pmax150 W
Hertz HMX 6.5 LD 2 Way

Hertz HMX 6.5 LD

4 Ω
6.5 2 Way
fS65 Hz
SD125 cm²
50 - 25000 Hz
QTS0.70
xmax3.7 mm
SPL1W87.5 dB
Bl/√RE2.78
Pmax150 W
Hertz HMX 6.5 2 Way

Hertz HMX 6.5

4 Ω
6.5 2 Way
fS65 Hz
SD125 cm²
50 - 25000 Hz
QTS0.70
xmax3.7 mm
SPL1W87.5 dB
Bl/√RE2.78
Pmax150 W
Discontinued
Hertz ECX 570.5 2 Way

Hertz ECX 570.5

4 Ω
5 x 7 2 Way
fS76.5 Hz
SD152 cm²
60 - 23000 Hz
QTS0.67
xmax3 mm
SPL1W88.8 dB
Bl/√RE2.78
Pmax210 W
Discontinued
Hertz ECX 165.5 2 Way

Hertz ECX 165.5

4 Ω
6.5 2 Way
fS72 Hz
SD145 cm²
60 - 23000 Hz
QTS0.58
xmax3 mm
SPL1W89.2 dB
Bl/√RE2.78
Pmax210 W
Discontinued
Hertz ECX 130.5 2 Way

Hertz ECX 130.5

4 Ω
5 2 Way
fS82 Hz
SD95.2 cm²
70 - 23000 Hz
QTS0.62
xmax3 mm
SPL1W88.2 dB
Bl/√RE2.27
Pmax150 W
Hertz DCX 87.3 2 Way

Hertz DCX 87.3

4 Ω
3.4 2 Way
fS190 Hz
SD37.6 cm²
130 - 21000 Hz
QTS1.00
xmax1.5 mm
SPL1W89 dB
Bl/√RE1.42
Pmax60 W

Hertz DCX 710.3

4 Ω
7 x 10 2 Way
fS69 Hz
SD260 cm²
40 - 21000 Hz
QTS1.06
xmax4 mm
SPL1W90.6 dB
Bl/√RE2.7
Pmax300 W
Hertz DCX 690.3 2 Way

Hertz DCX 690.3

4 Ω
6 x 9 2 Way
fS66 Hz
SD228 cm²
45 - 21000 Hz
QTS1.12
xmax2 mm
SPL1W89.9 dB
Bl/√RE2.12
Pmax180 W
Hertz DCX 570.3 2 Way

Hertz DCX 570.3

4 Ω
5 x 7 2 Way
fS81 Hz
SD145 cm²
60 - 21000 Hz
QTS0.82
xmax2 mm
SPL1W89.2 dB
Bl/√RE2.37
Pmax120 W
Hertz DCX 460.3 2 Way

Hertz DCX 460.3

4 Ω
4 x 6 2 Way
fS90 Hz
SD103 cm²
65 - 21000 Hz
QTS0.79
xmax2 mm
SPL1W90 dB
Bl/√RE2.09
Pmax80 W
Hertz DCX 170.3 2 Way

Hertz DCX 170.3

4 Ω
6.7 2 Way
fS85 Hz
SD141 cm²
60 - 21000 Hz
QTS0.95
xmax2 mm
SPL1W89.9 dB
Bl/√RE1.95
Pmax100 W
Hertz DCX 165.3 2 Way

Hertz DCX 165.3

4 Ω
6.5 2 Way
fS68 Hz
SD143 cm²
60 - 21000 Hz
QTS0.85
xmax2 mm
SPL1W88.8 dB
Bl/√RE2.2
Pmax120 W
Hertz DCX 160.3 2 Way

Hertz DCX 160.3

4 Ω
6 2 Way
fS70 Hz
SD118 cm²
50 - 21000 Hz
QTS0.62
xmax2.7 mm
SPL1W88.7 dB
Bl/√RE2.52
Pmax120 W
Hertz DCX 130.3 2 Way

Hertz DCX 130.3

4 Ω
5 2 Way
fS82 Hz
SD98.4 cm²
65 - 21000 Hz
QTS0.76
xmax2 mm
SPL1W88.1 dB
Bl/√RE2.09
Pmax80 W
Hertz DCX 100.3 2 Way

Hertz DCX 100.3

4 Ω
4 2 Way
fS115 Hz
SD56.2 cm²
70 - 21000 Hz
QTS0.79
xmax1.5 mm
SPL1W86.3 dB
Bl/√RE1.93
Pmax60 W
Hertz CX 570 2 Way

Hertz CX 570

4 Ω
5 x 7 2 Way
fS70 Hz
SD152 cm²
55 - 22000 Hz
QTS0.67
xmax3.5 mm
SPL1W89.2 dB
Bl/√RE2.7
Pmax140 W
Hertz CX 165 2 Way

Hertz CX 165

4 Ω
6.5 2 Way
fS65 Hz
SD137 cm²
55 - 22000 Hz
QTS0.60
xmax3.5 mm
SPL1W88 dB
Bl/√RE2.68
Pmax140 W
Hertz CX 130 2 Way

Hertz CX 130

4 Ω
5 2 Way
fS80 Hz
SD95 cm²
65 - 22 Hz
QTS0.56
xmax3.1 mm
SPL1W88.4 dB
Bl/√RE2.35
Pmax100 W
Hertz CX 100 2 Way

Hertz CX 100

4 Ω
4 2 Way
fS100 Hz
SD58.7 cm²
80 - 22 Hz
QTS0.72
xmax2.3 mm
SPL1W86.5 dB
Bl/√RE1.96
Pmax80 W
Hertz CPX 165 PRO 2 Way

Hertz CPX 165 PRO

4 Ω
6.5 2 Way
fS60 Hz
SD133 cm²
45 - 22000 Hz
QTS0.55
xmax3.9 mm
SPL1W87.7 dB
Bl/√RE2.92
Pmax285 W
