46 results
Brand
ATOHMAcoustic EleganceAudesAurum CantusB&C SpeakerBMSBRAXBeymaBlack HydraCT SoundsCelestionCerwin VegaCiareD.A.S. AudioDB DriveDayton AudioESXETONEighteen SoundEminenceFaitalPROFaneFi Car AudioFocalFostexFountekGRSGoldwoodHELIXHertzJL AudioJensenKICKERKICXKartesianLaVoceLowtherMATCHMD LabMONACORMTX AudioMicro-PrecisionMorelObertonP.AudioPHL audioPRV AudioPUNKTKILDEPeerlessPioneerPowerBassPrecision DevicesPrideRCFRadianReckhornRockford FosgateSB AcousticsSEASSICASUPRAVOXScan-SpeakSkar AudioTang BandVISATONVOLTWVLWavecoraccutonmivoc
Type
SubwooferWooferMid BassMid-rangeFull-rangeCoaxial2 Way2 Way Kit3 WayBass Guitar SpeakerGuitar SpeakerLow frequencyMiniatureShallow SubwooferShallow WooferShallow Mid-WooferTriaxial
Available on
Amazon.comParts Express
•
Nominal diameter
″
•
SensitivitySPL1W
dB

Thiele & Small parameters

•
Resonance frequencyfS
Hz
•
Mechanical quality factorQMS
•
Electrical quality factorQES
•
Total quality factorQTS

Large signal parameters

•
Maximum linear excursionxmax
mm
•
Air volume displaced at xmaxVD
cm³
•
Program powerPmax
W

Voice Coil & Magnet

•
Nominal impedanceZ
Ω
•
DC resistanceRE
Ω
•
Force factorBl
N/A
•
Motor constantBl/√RE
N/√W
•
InductanceLE
mH
•
VC Diameter
mm

Diaphragm

•
Effective diameter
mm
•
Effective areaSD
cm²
•
Moving massMMS
g

Suspensions

•
StiffnessKMS
N/mm
•
ComplianceCMS
µm/N
•
Equivalent volume to CMSVAS
L
•
Mechanical resistanceRMS
N·s/m

Dimensions

•
Overall size
mm
•
Baffle cutout diameter
mm
•
Overall depth
mm
•
Mounting depth
mm
•
Volume occupied
L
•
Net weight
kg
LaVoce WAN143.00 Woofer

LaVoce WAN143.00

8 Ω
13.5″ Woofer
fS45 Hz
SD713 cm²
45 - 3000 Hz
QTS0.35
xmax7.5 mm
SPL1W95.3 dB
Bl/√RE8.12
Pmax1000 W
LaVoce WAN082.02 Woofer

LaVoce WAN082.02

8 Ω
8″ Woofer
fS80 Hz
SD220 cm²
80 - 5000 Hz
QTS0.23
xmax5.8 mm
SPL1W95.3 dB
Bl/√RE7.79
Pmax400 W
LaVoce WAF153.03 Woofer

LaVoce WAF153.03

8 Ω
15″ Woofer
fS44 Hz
SD855 cm²
40 - 3000 Hz
QTS0.23
xmax6.7 mm
SPL1W97.7 dB
Bl/√RE11.1
Pmax1000 W
LaVoce WAN153.01 Woofer

LaVoce WAN153.01

8 Ω
15″ Woofer
fS44 Hz
SD855 cm²
40 - 2000 Hz
QTS0.24
xmax6.6 mm
SPL1W97.3 dB
Bl/√RE10.7
Pmax1200 W
LaVoce WAN123.01 Woofer

LaVoce WAN123.01

8 Ω
12″ Woofer
fS57 Hz
SD531 cm²
40 - 2000 Hz
QTS0.24
xmax6.6 mm
SPL1W96.1 dB
Bl/√RE10.5
Pmax1000 W
LaVoce WAN061.80 Woofer

LaVoce WAN061.80

8 Ω
6.5″ Woofer
fS60 Hz
SD132 cm²
60 - 5500 Hz
QTS0.27
xmax5.2 mm
SPL1W91 dB
Bl/√RE4.52
Pmax400 W
LaVoce WXF15.800 Woofer

LaVoce WXF15.800

8 Ω
15″ Woofer
fS47 Hz
SD855 cm²
40 - 2000 Hz
QTS0.36
xmax7.7 mm
SPL1W95.3 dB
Bl/√RE10
Pmax1600 W
LaVoce WXF15.400 Woofer

LaVoce WXF15.400

8 Ω
15″ Woofer
fS44 Hz
SD855 cm²
50 - 3000 Hz
QTS0.31
xmax5.2 mm
SPL1W97.8 dB
Bl/√RE8
Pmax800 W
LaVoce WSN152.50 Woofer

LaVoce WSN152.50

8 Ω
15″ Woofer
fS43 Hz
SD855 cm²
45 - 3000 Hz
QTS0.49
xmax4.7 mm
SPL1W95.4 dB
Bl/√RE6.86
Pmax500 W
LaVoce WSN122.50 Woofer

LaVoce WSN122.50

8 Ω
12″ Woofer
fS53 Hz
SD531 cm²
50 - 3000 Hz
QTS0.36
xmax4.7 mm
SPL1W95.4 dB
Bl/√RE6.64
Pmax500 W
LaVoce WSN102.50 Woofer

LaVoce WSN102.50

8 Ω
10″ Woofer
fS76 Hz
SD350 cm²
75 - 3000 Hz
QTS0.39
xmax2.9 mm
SPL1W94.7 dB
Bl/√RE6.35
Pmax600 W
LaVoce WSN061.52 Woofer

LaVoce WSN061.52

8 Ω
6.5″ Woofer
fS90 Hz
SD132 cm²
90 - 6000 Hz
QTS0.39
xmax3.8 mm
SPL1W91.8 dB
Bl/√RE4.18
Pmax250 W
LaVoce WSN041.00 Woofer

LaVoce WSN041.00

8 Ω
4″ Woofer
fS104 Hz
SD56 cm²
100 - 12000 Hz
QTS0.30
xmax4 mm
SPL1W89.7 dB
Bl/√RE3.51
Pmax80 W
LaVoce WSF152.50 Woofer

LaVoce WSF152.50

8 Ω
15″ Woofer
fS46 Hz
SD855 cm²
45 - 3000 Hz
QTS0.50
xmax4.7 mm
SPL1W95.4 dB
Bl/√RE6.83
Pmax500 W
LaVoce WSF122.50 Woofer

LaVoce WSF122.50

8 Ω
12″ Woofer
fS49 Hz
SD531 cm²
50 - 3000 Hz
QTS0.33
xmax4.7 mm
SPL1W95.2 dB
Bl/√RE7.23
Pmax500 W
LaVoce WSF122.02 Woofer

LaVoce WSF122.02

8 Ω
12″ Woofer
fS51 Hz
SD531 cm²
50 - 3000 Hz
QTS0.41
xmax4.3 mm
SPL1W95.7 dB
Bl/√RE5.62
Pmax400 W
LaVoce WSF102.50 Woofer

LaVoce WSF102.50

8 Ω
10″ Woofer
fS64 Hz
SD350 cm²
60 - 2000 Hz
QTS0.31
xmax4.8 mm
SPL1W95.4 dB
Bl/√RE6.36
Pmax500 W
LaVoce WSF102.00 Woofer

LaVoce WSF102.00

8 Ω
10″ Woofer
fS65 Hz
SD350 cm²
60 - 4000 Hz
QTS0.45
xmax5.2 mm
SPL1W94.4 dB
Bl/√RE5.1
Pmax350 W
LaVoce WSF081.82 Woofer

LaVoce WSF081.82

8 Ω
8″ Woofer
fS79 Hz
SD220 cm²
80 - 5000 Hz
QTS0.38
xmax6.2 mm
SPL1W93.5 dB
Bl/√RE4.71
Pmax300 W
LaVoce WSF061.52 Woofer

LaVoce WSF061.52

8 Ω
6.5″ Woofer
fS91 Hz
SD143 cm²
90 - 5000 Hz
QTS0.34
xmax3.8 mm
SPL1W93 dB
Bl/√RE4.61
Pmax250 W
LaVoce WSF051.02 Woofer

LaVoce WSF051.02

8 Ω
5″ Woofer
fS106 Hz
SD86 cm²
100 - 5000 Hz
QTS0.60
xmax3.1 mm
SPL1W89.3 dB
Bl/√RE2.7
Pmax120 W
Discontinued
LaVoce WSF041.00 Woofer

LaVoce WSF041.00

8 Ω
4″ Woofer
fS123 Hz
SD54.1 cm²
120 - 11000 Hz
QTS0.57
xmax2.8 mm
SPL1W88.1 dB
Bl/√RE2.47
Pmax80 W
LaVoce WSF030.70 Woofer

LaVoce WSF030.70

8 Ω
3″ Woofer
fS112 Hz
SD33 cm²
100 - 12000 Hz
QTS0.61
xmax3.3 mm
SPL1W84.2 dB
Bl/√RE1.85
Pmax60 W
LaVoce WAN154.02 Woofer

LaVoce WAN154.02

8 Ω
15″ Woofer
fS40 Hz
SD810 cm²
40 - 3000 Hz
QTS0.24
xmax8 mm
SPL1W97.1 dB
Bl/√RE10.9
Pmax1400 W
LaVoce WAN153.00 Woofer

LaVoce WAN153.00

8 Ω
15″ Woofer
fS43 Hz
SD855 cm²
45 - 3000 Hz
QTS0.41
xmax7 mm
SPL1W95.5 dB
Bl/√RE7.99
Pmax1000 W
LaVoce WAN124.01 Woofer

LaVoce WAN124.01

8 Ω
12″ Woofer
fS39 Hz
SD531 cm²
40 - 2000 Hz
QTS0.21
xmax8.3 mm
SPL1W94.3 dB
Bl/√RE11.4
Pmax2000 W
LaVoce WAN123.00 Woofer

LaVoce WAN123.00

8 Ω
12″ Woofer
fS49 Hz
SD531 cm²
50 - 3000 Hz
QTS0.27
xmax6.9 mm
SPL1W95.8 dB
Bl/√RE8.17
Pmax1000 W
LaVoce WAN103.01 Woofer

LaVoce WAN103.01

8 Ω
10″ Woofer
fS70 Hz
SD350 cm²
70 - 3500 Hz
QTS0.22
xmax5 mm
SPL1W96.7 dB
Bl/√RE8.77
Pmax900 W
LaVoce WAN102.50LD Woofer

LaVoce WAN102.50LD

8 Ω
10″ Woofer
fS52 Hz
SD350 cm²
50 - 4000 Hz
QTS0.40
xmax11.5 mm
SPL1W90.7 dB
Bl/√RE7.27
Pmax600 W
LaVoce WAN102.50 Woofer

LaVoce WAN102.50

8 Ω
10″ Woofer
fS78 Hz
SD350 cm²
80 - 4000 Hz
QTS0.35
xmax5.1 mm
SPL1W96 dB
Bl/√RE6.47
Pmax600 W
Discontinued
LaVoce WAN082.50 Woofer

LaVoce WAN082.50

8 Ω
8″ Woofer
fS76 Hz
SD227 cm²
75 - 2000 Hz
QTS0.33
xmax4.1 mm
SPL1W92.6 dB
Bl/√RE6.29
Pmax500 W
LaVoce WAN082.01 Woofer

LaVoce WAN082.01

8 Ω
8″ Woofer
fS85 Hz
SD220 cm²
80 - 5000 Hz
QTS0.32
xmax5.8 mm
SPL1W93.7 dB
Bl/√RE6.4
Pmax400 W
LaVoce WAF154.03 Woofer

LaVoce WAF154.03

8 Ω
15″ Woofer
fS40 Hz
SD855 cm²
40 - 3000 Hz
QTS0.26
xmax5.2 mm
SPL1W99.1 dB
Bl/√RE9.44
Pmax1700 W
LaVoce WAF153.02 Woofer

LaVoce WAF153.02

8 Ω
15″ Woofer
fS36 Hz
SD855 cm²
40 - 4000 Hz
QTS0.29
xmax4.9 mm
SPL1W98.2 dB
Bl/√RE8.2
Pmax1000 W
LaVoce WAF153.00 Woofer

LaVoce WAF153.00

8 Ω
15″ Woofer
fS43 Hz
SD855 cm²
40 - 3000 Hz
QTS0.37
xmax7 mm
SPL1W95.7 dB
Bl/√RE8.25
Pmax1000 W
LaVoce WAF124.02 Woofer

LaVoce WAF124.02

8 Ω
12″ Woofer
fS49 Hz
SD531 cm²
50 - 2500 Hz
QTS0.33
xmax8.2 mm
SPL1W93.9 dB
Bl/√RE8.15
Pmax1200 W
LaVoce WAF124.01 Woofer

LaVoce WAF124.01

8 Ω
12″ Woofer
fS423 Hz
SD531 cm²
40 - 1000 Hz
QTS0.22
xmax8.3 mm
SPL1W92.8 dB
Bl/√RE11.1
Pmax2000 W
LaVoce WAF123.02 Woofer

LaVoce WAF123.02

8 Ω
12″ Woofer
fS47 Hz
SD531 cm²
45 - 3000 Hz
QTS0.25
xmax4.4 mm
SPL1W97 dB
Bl/√RE8
Pmax1000 W
LaVoce WAF123.01 Woofer

LaVoce WAF123.01

8 Ω
12″ Woofer
fS65 Hz
SD531 cm²
65 - 3000 Hz
QTS0.40
xmax7.5 mm
SPL1W95.2 dB
Bl/√RE7.8
Pmax1000 W
LaVoce WAF123.00 Woofer

LaVoce WAF123.00

8 Ω
12″ Woofer
fS50 Hz
SD531 cm²
500 - 3000 Hz
QTS0.26
xmax7 mm
SPL1W95.8 dB
Bl/√RE8.28
Pmax1000 W
