201 results
Nominal diameter
SensitivitySPL1W
dB

Thiele & Small parameters

Resonance frequencyfS
Hz
Mechanical quality factorQMS
Electrical quality factorQES
Total quality factorQTS

Large signal parameters

Maximum linear excursionxmax
mm
Air volume displaced at xmaxVD
cm³
Program powerPmax
W

Voice Coil & Magnet

Nominal impedanceZ
Ω
DC resistanceRE
Ω
Force factorBl
N/A
Motor constantBl/√RE
N/√W
InductanceLE
mH
VC Diameter
mm

Diaphragm

Effective diameter
mm
Effective areaSD
cm²
Moving massMMS
g

Suspensions

StiffnessKMS
N/mm
ComplianceCMS
µm/N
Equivalent volume to CMSVAS
L
Mechanical resistanceRMS
N·s/m

Dimensions

Overall size
mm
Baffle cutout diameter
mm
Overall depth
mm
Mounting depth
mm
Volume occupied
L
Net weight
kg
Dayton Audio RS75-8 Full-range
3Full-range
fS
185 Hz
SD
12 cm²
160 - 20000 Hz
QTS
1.07
xmax
1.3 mm
SPL1W
81 dB
Bl/√RE
1.02
Pmax
30 W
Dayton Audio PSS555-8 Subwoofer
21Subwoofer
fS
28 Hz
SD
1735 cm²
27 - 2500 Hz
QTS
0.33
xmax
11.0 mm
SPL1W
96 dB
Bl/√RE
13
Pmax
2000 W
Dayton Audio PCX12-8 Woofer
12Woofer
fS
41 Hz
SD
511 cm²
50 - 5000 Hz
QTS
0.56
xmax
2.0 mm
SPL1W
94 dB
Bl/√RE
3.67
Pmax
400 W
Dayton Audio MX15-22 Subwoofer
15Subwoofer
fS
22 Hz
SD
820 cm²
18 - 400 Hz
QTS
0.40
xmax
19.0 mm
SPL1W
87 dB
Bl/√RE
10
Pmax
1600 W
Dayton Audio MX12-22 Subwoofer
12Subwoofer
fS
29 Hz
SD
515 cm²
23 - 450 Hz
QTS
0.35
xmax
15.5 mm
SPL1W
86 dB
Bl/√RE
11
Pmax
1200 W
Dayton Audio MX10-22 Subwoofer
10Subwoofer
fS
33 Hz
SD
357 cm²
25 - 500 Hz
QTS
0.46
xmax
11.6 mm
SPL1W
84 dB
Bl/√RE
8.34
Pmax
800 W
Dayton Audio MB820-8 Mid Bass
8Mid Bass
fS
69 Hz
SD
244 cm²
100 - 7500 Hz
QTS
0.46
xmax
4.0 mm
SPL1W
93 dB
Bl/√RE
4.19
Pmax
400 W
Dayton Audio MB620-8 Mid Bass
6.5Mid Bass
fS
104 Hz
SD
133 cm²
100 - 7000 Hz
QTS
0.59
xmax
2.0 mm
SPL1W
92 dB
Bl/√RE
2.86
Pmax
400 W
Dayton Audio E150HE-44 Subwoofer
5.5Subwoofer
fS
40 Hz
SD
95 cm²
30 - 4000 Hz
QTS
0.39
xmax
14.7 mm
SPL1W
82 dB
Bl/√RE
3.81
Pmax
400 W
Dayton Audio CE78PF-4 Full-range
3Full-range
fS
100 Hz
SD
30 cm²
200 - 18000 Hz
QTS
0.99
xmax
1.4 mm
SPL1W
83 dB
Bl/√RE
1.15
Pmax
20 W
Dayton Audio CE70PR-4 Full-range
2.5Full-range
fS
109 Hz
SD
25 cm²
85 - 13000 Hz
QTS
0.63
xmax
4.0 mm
SPL1W
82 dB
Bl/√RE
1.76
Pmax
40 W
Dayton Audio CE67PR-4 Full-range
2Full-range
fS
218 Hz
SD
17 cm²
218 - 20000 Hz
QTS
0.92
xmax
2.2 mm
SPL1W
83 dB
Bl/√RE
1.51
Pmax
30 W
Dayton Audio CE58N-10 Full-range
2Full-range
fS
177 Hz
SD
15 cm²
130 - 10000 Hz
QTS
0.69
xmax
2.1 mm
SPL1W
82 dB
Bl/√RE
1.37
Pmax
30 W
Dayton Audio CE54N-4 Full-range
2Full-range
fS
168 Hz
SD
15 cm²
150 - 17000 Hz
QTS
0.58
xmax
1.4 mm
SPL1W
81 dB
Bl/√RE
2.01
Pmax
30 W
Dayton Audio CE53N-4 Full-range
2Full-range
fS
197 Hz
SD
8.6 cm²
200 - 20000 Hz
QTS
1.00
xmax
2.0 mm
SPL1W
80 dB
Bl/√RE
0.918
Pmax
20 W
Dayton Audio CE52N-4 Full-range
2Full-range
fS
164 Hz
SD
13 cm²
120 - 20000 Hz
QTS
0.59
xmax
0.9 mm
SPL1W
82 dB
Bl/√RE
1.38
Pmax
10 W
Dayton Audio CE4895-8 Full-range
2 x 3.75Full-range
fS
123 Hz
SD
25 cm²
100 - 15000 Hz
QTS
0.53
xmax
1.8 mm
SPL1W
84 dB
Bl/√RE
1.91
Pmax
44 W
Dayton Audio CE4876-8 Full-range
2 x 3Full-range
fS
203 Hz
SD
26 cm²
150 - 17000 Hz
QTS
1.42
xmax
2.2 mm
SPL1W
88 dB
Bl/√RE
1.1
Pmax
30 W
Dayton Audio CE4876-16 Full-range
2 x 3Full-range
fS
150 Hz
SD
26 cm²
150 - 17000 Hz
QTS
1.14
xmax
2.5 mm
SPL1W
85 dB
Bl/√RE
1.13
Pmax
20 W
Dayton Audio CE48-4 Full-range
2Full-range
fS
151 Hz
SD
9.1 cm²
120 - 20000 Hz
QTS
0.95
xmax
1.2 mm
SPL1W
77 dB
Bl/√RE
1.33
Pmax
10 W
Dayton Audio CE45N-4 Full-range
1.75Full-range
fS
178 Hz
SD
8.0 cm²
150 - 20000 Hz
QTS
0.89
xmax
1.1 mm
SPL1W
79 dB
Bl/√RE
0.928
Pmax
10 W
Dayton Audio CE4278-8 Full-range
1.25 x 3Full-range
fS
211 Hz
SD
16 cm²
150 - 17000 Hz
QTS
1.26
xmax
2.1 mm
SPL1W
84 dB
Bl/√RE
1.07
Pmax
20 W
Dayton Audio CE41N-4 Full-range
1.5Full-range
fS
170 Hz
SD
7.1 cm²
150 - 20000 Hz
QTS
0.53
xmax
0.7 mm
SPL1W
80 dB
Bl/√RE
1.21
Pmax
10 W
