42 results
Nominal diameter
SensitivitySPL1W
dB

Thiele & Small parameters

Resonance frequencyfS
Hz
Mechanical quality factorQMS
Electrical quality factorQES
Total quality factorQTS

Large signal parameters

Maximum linear excursionxmax
mm
Air volume displaced at xmaxVD
cm³
Program powerPmax
W

Voice Coil & Magnet

Nominal impedanceZ
Ω
DC resistanceRE
Ω
Force factorBl
N/A
Motor constantBl/√RE
N/√W
InductanceLE
mH
VC Diameter
mm

Diaphragm

Effective diameter
mm
Effective areaSD
cm²
Moving massMMS
g

Suspensions

StiffnessKMS
N/mm
ComplianceCMS
µm/N
Equivalent volume to CMSVAS
L
Mechanical resistanceRMS
N·s/m

Dimensions

Overall size
mm
Baffle cutout diameter
mm
Overall depth
mm
Mounting depth
mm
Volume occupied
L
Net weight
kg
DB Drive WDX8G0.2 Subwoofer
8Subwoofer
fS
42 Hz
SD
211 cm²
QTS
0.41
xmax
11.0 mm
SPL1W
84 dB
Bl/√RE
7.22
Pmax
800 W
DB Drive WDX8G5.4 Subwoofer
8Subwoofer
fS
34 Hz
SD
201 cm²
QTS
0.52
xmax
22.5 mm
SPL1W
79 dB
Bl/√RE
7.68
Pmax
1800 W
DB Drive WDX8G5.2 Subwoofer
8Subwoofer
fS
34 Hz
SD
201 cm²
QTS
0.52
xmax
22.5 mm
SPL1W
79 dB
Bl/√RE
7.68
Pmax
1800 W
DB Drive WDX8G2F-4 Subwoofer
8Subwoofer
fS
40 Hz
SD
201 cm²
QTS
0.49
xmax
12.0 mm
SPL1W
82 dB
Bl/√RE
6.58
Pmax
700 W
DB Drive WDX8G2.2 Subwoofer
8Subwoofer
fS
46 Hz
SD
216 cm²
QTS
0.45
xmax
13.0 mm
SPL1W
81 dB
Bl/√RE
9.19
Pmax
1500 W
DB Drive WDX8G1.4 Subwoofer
8Subwoofer
fS
56 Hz
SD
214 cm²
QTS
0.68
xmax
12.5 mm
SPL1W
82 dB
Bl/√RE
8.34
Pmax
1200 W
DB Drive WDX8G0.4 Subwoofer
8Subwoofer
fS
42 Hz
SD
195 cm²
QTS
0.37
xmax
11.0 mm
SPL1W
83 dB
Bl/√RE
7.47
Pmax
800 W
DB Drive WDX6.5G2.2 Subwoofer
6.5Subwoofer
fS
49 Hz
SD
143 cm²
QTS
0.65
xmax
15.0 mm
SPL1W
80 dB
Bl/√RE
5.67
Pmax
1500 W
DB Drive WDX6.5G1.4 Subwoofer
6.5Subwoofer
fS
59 Hz
SD
143 cm²
QTS
0.68
xmax
10.0 mm
SPL1W
81 dB
Bl/√RE
5.89
Pmax
600 W
DB Drive WDX18G5.2 Subwoofer
18Subwoofer
fS
32 Hz
SD
1224 cm²
QTS
0.62
xmax
25.0 mm
SPL1W
89 dB
Bl/√RE
12
Pmax
6000 W
DB Drive WDX15G5.4 Subwoofer
15Subwoofer
fS
39 Hz
SD
832 cm²
QTS
0.56
xmax
25.0 mm
SPL1W
88 dB
Bl/√RE
11
Pmax
6000 W
DB Drive WDX15G5.2 Subwoofer
15Subwoofer
fS
38 Hz
SD
834 cm²
QTS
0.57
xmax
25.0 mm
SPL1W
88 dB
Bl/√RE
12
Pmax
6000 W
DB Drive WDX15G3.4 Subwoofer
15Subwoofer
fS
35 Hz
SD
830 cm²
QTS
0.83
xmax
23.0 mm
SPL1W
86 dB
Bl/√RE
8.89
Pmax
4000 W
DB Drive WDX15G2.2 Subwoofer
15Subwoofer
fS
37 Hz
SD
824 cm²
QTS
0.60
xmax
20.0 mm
SPL1W
88 dB
Bl/√RE
11
Pmax
2500 W
DB Drive WDX15G1.4 Subwoofer
15Subwoofer
fS
37 Hz
SD
843 cm²
QTS
0.66
xmax
14.0 mm
SPL1W
87 dB
Bl/√RE
11
Pmax
2000 W
DB Drive WDX12G5.4 Subwoofer
12Subwoofer
fS
40 Hz
SD
533 cm²
QTS
0.52
xmax
25.0 mm
SPL1W
86 dB
Bl/√RE
11
Pmax
6000 W
DB Drive WDX12G5.2 Subwoofer
12Subwoofer
fS
39 Hz
SD
534 cm²
QTS
0.53
xmax
25.0 mm
SPL1W
85 dB
Bl/√RE
11
Pmax
6000 W
DB Drive WDX12G3.4 Subwoofer
12Subwoofer
fS
36 Hz
SD
533 cm²
QTS
0.82
xmax
23.0 mm
SPL1W
83 dB
Bl/√RE
8.47
Pmax
4000 W
DB Drive WDX12G1.4 Subwoofer
12Subwoofer
fS
41 Hz
SD
531 cm²
QTS
0.62
xmax
14.0 mm
SPL1W
85 dB
Bl/√RE
11
Pmax
2000 W
DB Drive WDX12G0.4 Subwoofer
12Subwoofer
fS
35 Hz
SD
530 cm²
QTS
0.55
xmax
14.0 mm
SPL1W
85 dB
Bl/√RE
8.86
Pmax
1200 W
DB Drive WDX10G5.4 Subwoofer
10Subwoofer
fS
43 Hz
SD
365 cm²
QTS
0.49
xmax
25.0 mm
SPL1W
83 dB
Bl/√RE
12
Pmax
3000 W
DB Drive WDX10G5.2 Subwoofer
10Subwoofer
fS
40 Hz
SD
365 cm²
QTS
0.50
xmax
25.0 mm
SPL1W
82 dB
Bl/√RE
13
Pmax
3000 W
DB Drive WDX10G2F-4 Subwoofer
10Subwoofer
fS
35 Hz
SD
337 cm²
QTS
0.70
xmax
14.0 mm
SPL1W
82 dB
Bl/√RE
6.68
Pmax
1000 W
DB Drive WDX10G1.4 Subwoofer
10Subwoofer
fS
42 Hz
SD
372 cm²
QTS
0.49
xmax
14.0 mm
SPL1W
83 dB
Bl/√RE
11
Pmax
2000 W
DB Drive WDX10G0.4 Subwoofer
10Subwoofer
fS
38 Hz
SD
364 cm²
QTS
0.47
xmax
14.0 mm
SPL1W
84 dB
Bl/√RE
8.48
Pmax
1000 W
DB Drive WDX10G0.2 Subwoofer
10Subwoofer
fS
36 Hz
SD
363 cm²
QTS
0.36
xmax
14.0 mm
SPL1W
85 dB
Bl/√RE
10
Pmax
1000 W
DB Drive SPF12D4 Subwoofer
12Subwoofer
fS
23 Hz
SD
552 cm²
QTS
0.53
SPL1W
86 dB
Bl/√RE
6.61
Pmax
1000 W
DB Drive SPF10D4 Subwoofer
10Subwoofer
fS
27 Hz
SD
346 cm²
QTS
0.74
SPL1W
83 dB
Bl/√RE
4.98
Pmax
1000 W
DB Drive G7 8.4 Subwoofer
8Subwoofer
fS
50 Hz
SD
228 cm²
QTS
0.57
xmax
20.0 mm
SPL1W
80 dB
Bl/√RE
8.84
Pmax
2500 W
DB Drive G7 8.2 Subwoofer
8Subwoofer
fS
49 Hz
SD
222 cm²
QTS
0.52
xmax
20.0 mm
SPL1W
80 dB
Bl/√RE
9.66
Pmax
2500 W
DB Drive G7 15.2 Subwoofer
15Subwoofer
fS
23 Hz
SD
754 cm²
QTS
0.47
xmax
35.0 mm
SPL1W
84 dB
Bl/√RE
11
Pmax
8000 W
DB Drive G7 15.1 Subwoofer
15Subwoofer
fS
25 Hz
SD
755 cm²
QTS
0.39
xmax
35.0 mm
SPL1W
84 dB
Bl/√RE
15
Pmax
8000 W
DB Drive G7 12.2 Subwoofer
12Subwoofer
fS
30 Hz
SD
473 cm²
QTS
0.48
xmax
35.0 mm
SPL1W
82 dB
Bl/√RE
11
Pmax
8000 W
DB Drive G7 12.1 Subwoofer
12Subwoofer
fS
29 Hz
SD
470 cm²
QTS
0.37
xmax
35.0 mm
SPL1W
83 dB
Bl/√RE
14
Pmax
8000 W
DB Drive WDX8G2.4 Subwoofer
8Subwoofer
fS
46 Hz
SD
201 cm²
QTS
0.45
xmax
13.0 mm
SPL1W
84 dB
Bl/√RE
9.75
Pmax
1500 W
DB Drive WDX6.5G2.4 Subwoofer
6.5Subwoofer
fS
52 Hz
SD
142 cm²
QTS
0.61
xmax
15.0 mm
SPL1W
80 dB
Bl/√RE
6.6
Pmax
1500 W
DB Drive WDX15G2.4 Subwoofer
15Subwoofer
fS
37 Hz
SD
827 cm²
QTS
0.62
xmax
20.0 mm
SPL1W
91 dB
Bl/√RE
12
Pmax
2500 W
DB Drive WDX12G2.4 Subwoofer
12Subwoofer
fS
42 Hz
SD
529 cm²
QTS
0.48
xmax
20.0 mm
SPL1W
87 dB
Bl/√RE
11
Pmax
2500 W
DB Drive WDX12G2.2 Subwoofer
12Subwoofer
fS
44 Hz
SD
507 cm²
QTS
0.50
xmax
20.0 mm
SPL1W
87 dB
Bl/√RE
11
Pmax
2500 W
