SB Acoustics SB36WBAC21-88 Ω | |
|---|---|
| 1″ Full-range | |
| fS | 160 Hz |
| SD | 4.2 cm² |
| QTS | 0.61 |
| xmax | 1.8 mm |
| SPL1W | 73.8 dB |
| Bl/√RE | 0.87 |
| Pmax | 10 W |
422 results
Brand
Type
Available on
•
Nominal diameter
″
•
SensitivitySPL1W
dB
Thiele & Small parameters
•
Resonance frequencyfS
Hz
•
Mechanical quality factorQMS
•
Electrical quality factorQES
•
Total quality factorQTS
Large signal parameters
•
Maximum linear excursionxmax
mm
•
Air volume displaced at xmaxVD
cm³
•
Program powerPmax
W
Voice Coil & Magnet
•
Nominal impedanceZ
Ω
•
DC resistanceRE
Ω
•
Force factorBl
N/A
•
Motor constantBl/√RE
N/√W
•
InductanceLE
mH
•
VC Diameter
mm
Diaphragm
•
Effective diameter
mm
•
Effective areaSD
cm²
•
Moving massMMS
g
Suspensions
•
StiffnessKMS
N/mm
•
ComplianceCMS
µm/N
•
Equivalent volume to CMSVAS
L
•
Mechanical resistanceRMS
N·s/m
Dimensions
•
Overall size
mm
•
Baffle cutout diameter
mm
•
Overall depth
mm
•
Mounting depth
mm
•
Volume occupied
L
•
Net weight
kg
.jpg.webp)
SB Acoustics SB36WBAC21-44 Ω | |
|---|---|
| 1″ Full-range | |
| fS | 200 Hz |
| SD | 4.2 cm² |
| QTS | 0.41 |
| xmax | 1.8 mm |
| SPL1W | 73 dB |
| Bl/√RE | 0.95 |
| Pmax | 10 W |
.png.webp)
SB Acoustics SB20FRPC30-88 Ω | |
|---|---|
| 8″ Full-range | |
| fS | 39.4 Hz |
| SD | 216 cm² |
| QTS | 0.45 |
| xmax | 4.1 mm |
| SPL1W | 91.6 dB |
| Bl/√RE | 2.92 |
| Pmax | 80 W |
.png.webp)
Tang Band W1-2396S4 Ω | |
|---|---|
| 1″ Full-range | |
| fS | 180 Hz |
| SD | 9.6 cm² |
| 180 - 20000 Hz | |
| QTS | 0.59 |
| xmax | 1.1 mm |
| SPL1W | 80.7 dB |
| Bl/√RE | 1.12 |
| Pmax | 6 W |
.jpg.webp)
PRV Audio 8FR2508 Ω | |
|---|---|
| 8″ Full-range | |
| fS | 75.6 Hz |
| SD | 227 cm² |
| 50 - 18000 Hz | |
| QTS | 1.02 |
| xmax | 3.5 mm |
| SPL1W | 92 dB |
| Bl/√RE | 2.54 |
| Pmax | 250 W |
.jpg.webp)
PRV Audio 8CX380-4 SLIM4 Ω | |
|---|---|
| 8″ Coaxial | |
| fS | 92.1 Hz |
| SD | 235 cm² |
| 100 - 20000 Hz | |
| QTS | 1.09 |
| xmax | 2.8 mm |
| SPL1W | 94.1 dB |
| Bl/√RE | 2.55 |
| Pmax | 380 W |
.jpg.webp)
PRV Audio 6FR2008 Ω | |
|---|---|
| 6″ Full-range | |
| fS | 112 Hz |
| SD | 143 cm² |
| 80 - 20000 Hz | |
| QTS | 1.29 |
| xmax | 3.5 mm |
| SPL1W | 92.7 dB |
| Bl/√RE | 2.04 |
| Pmax | 200 W |
.jpg.webp)
PRV Audio 6CX380-4 SLIM4 Ω | |
|---|---|
| 6.5″ Coaxial | |
| fS | 112 Hz |
| SD | 143 cm² |
| 100 - 20000 Hz | |
| QTS | 0.77 |
| xmax | 2.8 mm |
| SPL1W | 92.8 dB |
| Bl/√RE | 2.69 |
| Pmax | 380 W |
.jpg.webp)
PRV Audio 69FR250-44 Ω | |
|---|---|
| 6 x 9″ Full-range | |
| fS | 82.1 Hz |
| SD | 200 cm² |
| 75 - 18000 Hz | |
| QTS | 0.70 |
| xmax | 3.5 mm |
| SPL1W | 92.1 dB |
| Bl/√RE | 3.26 |
| Pmax | 250 W |
.jpg.webp)
PRV Audio 4MR60-NDY-44 Ω | |
|---|---|
| 4″ Full-range | |
| fS | 95.6 Hz |
| SD | 55.4 cm² |
| 90 - 20000 Hz | |
| QTS | 0.85 |
| xmax | 1.4 mm |
| SPL1W | 86 dB |
| Bl/√RE | 1.55 |
| Pmax | 60 W |
.jpg.webp)
PRV Audio 3MR40-NDY-44 Ω | |
|---|---|
| 3″ Full-range | |
| fS | 153 Hz |
| SD | 33.2 cm² |
| 120 - 20000 Hz | |
| QTS | 0.77 |
| xmax | 1.4 mm |
| SPL1W | 85.9 dB |
| Bl/√RE | 1.59 |
| Pmax | 40 W |
.jpg.webp)
PRV Audio 10FR3008 Ω | |
|---|---|
| 10″ Full-range | |
| fS | 60.1 Hz |
| SD | 394 cm² |
| 50 - 14000 Hz | |
| QTS | 0.65 |
| xmax | 4 mm |
| SPL1W | 94.3 dB |
| Bl/√RE | 4.21 |
| Pmax | 300 W |
.jpg.webp)
Wavecor FR4X6WA028 Ω | |
|---|---|
| 1.75 x 2.5″ Full-range | |
| fS | 179 Hz |
| SD | 15 cm² |
| 179 - 20000 Hz | |
| QTS | 0.99 |
| xmax | 2 mm |
| SPL1W | 82.4 dB |
| Bl/√RE | 1.1 |
| Pmax | 15 W |
.webp.webp)
Wavecor FR084WA0364 Ω | |
|---|---|
| 3.25″ Full-range | |
| fS | 116 Hz |
| SD | 38 cm² |
| 116 - 20000 Hz | |
| QTS | 1.78 |
| xmax | 2.5 mm |
| SPL1W | 86.3 dB |
| Bl/√RE | 0.97 |
| Pmax | 25 W |
.jpg.webp)
Wavecor FR070WA054 Ω | |
|---|---|
| 2.75″ Full-range | |
| fS | 89 Hz |
| SD | 22 cm² |
| 89 - 20000 Hz | |
| QTS | 0.47 |
| xmax | 2.7 mm |
| SPL1W | 81.4 dB |
| Bl/√RE | 2.04 |
| Pmax | 15 W |
.webp.webp)
Wavecor FR055WA0564 Ω | |
|---|---|
| 2″ Full-range | |
| fS | 135 Hz |
| SD | 15.6 cm² |
| 135 - 20000 Hz | |
| QTS | 1.67 |
| xmax | 1.4 mm |
| SPL1W | 82.5 dB |
| Bl/√RE | 0.75 |
| Pmax | 20 W |
.jpg.webp)
Wavecor FR055WA048 Ω | |
|---|---|
| 2″ Full-range | |
| fS | 131 Hz |
| SD | 15.6 cm² |
| 131 - 20000 Hz | |
| QTS | 0.66 |
| xmax | 1.4 mm |
| SPL1W | 82.2 dB |
| Bl/√RE | 1.33 |
| Pmax | 20 W |
.jpg.webp)
Wavecor FR055WA034 Ω | |
|---|---|
| 2″ Full-range | |
| fS | 128 Hz |
| SD | 15.6 cm² |
| 128 - 20000 Hz | |
| QTS | 0.51 |
| xmax | 1.4 mm |
| SPL1W | 82.6 dB |
| Bl/√RE | 1.53 |
| Pmax | 20 W |
.jpg.webp)
Wavecor FR4X6WA014 Ω | |
|---|---|
| 1.75 x 2.5″ Full-range | |
| fS | 173 Hz |
| SD | 15 cm² |
| 173 - 20000 Hz | |
| QTS | 0.86 |
| xmax | 2 mm |
| SPL1W | 82 dB |
| Bl/√RE | 1.21 |
| Pmax | 15 W |
.jpg.webp)
PUNKTKILDE FSB512030-38148 Ω | |
|---|---|
| 3″ Full-range | |
| fS | 120 Hz |
| SD | 28.3 cm² |
| QTS | 0.75 |
| xmax | 2.3 mm |
| SPL1W | 81.7 dB |
| Bl/√RE | 1.56 |
| Pmax | 40 W |
.jpg.webp)
PUNKTKILDE FSB511017-14004 Ω | |
|---|---|
| 1.5″ Full-range | |
| fS | 185 Hz |
| SD | 8 cm² |
| QTS | 0.44 |
| xmax | 2.7 mm |
| SPL1W | 79.9 dB |
| Bl/√RE | 1.61 |
| Pmax | 20 W |
.jpg.webp)
PUNKTKILDE FSA011020-04014 Ω | |
|---|---|
| 2″ Full-range | |
| fS | 150 Hz |
| SD | 13.2 cm² |
| QTS | 0.52 |
| xmax | 2.3 mm |
| SPL1W | 80.4 dB |
| Bl/√RE | 2.03 |
| Pmax | 20 W |
.jpg.webp)
PUNKTKILDE FSA010815-03003 Ω | |
|---|---|
| 1.5″ Full-range | |
| fS | 178 Hz |
| SD | 8.6 cm² |
| QTS | 0.51 |
| xmax | 1.5 mm |
| SPL1W | 78.3 dB |
| Bl/√RE | 1.93 |
| Pmax | 16 W |
.jpg.webp)
PUNKTKILDE AUK600814-17806 Ω | |
|---|---|
| 3.25″ Full-range | |
| fS | 120 Hz |
| SD | 36.3 cm² |
| QTS | 1.11 |
| xmax | 3.9 mm |
| SPL1W | 83.4 dB |
| Bl/√RE | 1.33 |
| Pmax | 40 W |
.jpg.webp)
PUNKTKILDE AUGWL1073-JN018 Ω | |
|---|---|
| 0.8″ Full-range | |
| fS | 230 Hz |
| SD | 8.6 cm² |
| QTS | 0.92 |
| xmax | 1.1 mm |
| SPL1W | 80.4 dB |
| Bl/√RE | 1.2 |
| Pmax | 10 W |
.jpg.webp)
PUNKTKILDE AUGPL0004-JN034 Ω | |
|---|---|
| 1.5″ Full-range | |
| fS | 116 Hz |
| SD | 9.9 cm² |
| QTS | 0.28 |
| xmax | 2.1 mm |
| SPL1W | 78 dB |
| Bl/√RE | 2.39 |
| Pmax | 20 W |
.jpg.webp)
PUNKTKILDE AUGPL0004-JN014 Ω | |
|---|---|
| 1.5″ Full-range | |
| fS | 180 Hz |
| SD | 7.3 cm² |
| QTS | 0.67 |
| xmax | 2.6 mm |
| SPL1W | 78.1 dB |
| Bl/√RE | 1.49 |
| Pmax | 20 W |
.jpg.webp)
PUNKTKILDE AUGFL3084-JN013 Ω | |
|---|---|
| 1.25″ Full-range | |
| fS | 573 Hz |
| SD | 8.7 cm² |
| QTS | 0.82 |
| xmax | 0.6 mm |
| SPL1W | 84.1 dB |
| Bl/√RE | 1.74 |
| Pmax | 20 W |
.jpg.webp)
PUNKTKILDE AUGFL3012-JN014 Ω | |
|---|---|
| 3″ Full-range | |
| fS | 202 Hz |
| SD | 33.1 cm² |
| QTS | 1.46 |
| xmax | 1.7 mm |
| SPL1W | 85 dB |
| Bl/√RE | 1.5 |
| Pmax | 30 W |
.jpg.webp)
PUNKTKILDE AUGFL2088-JN014 Ω | |
|---|---|
| 3″ Full-range | |
| fS | 97.8 Hz |
| SD | 28.8 cm² |
| QTS | 0.53 |
| xmax | 1.6 mm |
| SPL1W | 83.7 dB |
| Bl/√RE | 1.62 |
| Pmax | 30 W |
.jpg.webp)
PUNKTKILDE AUGFL2083-JN014 Ω | |
|---|---|
| 1.75″ Full-range | |
| fS | 152 Hz |
| SD | 10.4 cm² |
| QTS | 1.39 |
| xmax | 3.8 mm |
| SPL1W | 77.3 dB |
| Bl/√RE | 1.11 |
| Pmax | 30 W |
.jpg.webp)
PUNKTKILDE AUGFL2079-JN014 Ω | |
|---|---|
| 2 x 4.5″ Full-range | |
| fS | 128 Hz |
| SD | 34.5 cm² |
| QTS | 1.85 |
| xmax | 3.5 mm |
| SPL1W | 84.8 dB |
| Bl/√RE | 1.16 |
| Pmax | 30 W |
.jpg.webp)
PUNKTKILDE AUGFL2022-JN014 Ω | |
|---|---|
| 2.5″ Full-range | |
| fS | 139 Hz |
| SD | 31.2 cm² |
| QTS | 0.79 |
| xmax | 1.7 mm |
| SPL1W | 82.6 dB |
| Bl/√RE | 2.02 |
| Pmax | 16 W |
.jpg.webp)
PUNKTKILDE AUGFL2003-JN014 Ω | |
|---|---|
| 1.5″ Full-range | |
| fS | 180 Hz |
| SD | 8.5 cm² |
| 180 - 40000 Hz | |
| QTS | 0.49 |
| xmax | 1.1 mm |
| SPL1W | 80.7 dB |
| Bl/√RE | 1.4 |
| Pmax | 10 W |
.jpg.webp)
PUNKTKILDE AUGFL2003-HM013 Ω | |
|---|---|
| 2″ Full-range | |
| fS | 135 Hz |
| SD | 13.2 cm² |
| QTS | 0.56 |
| xmax | 1.1 mm |
| SPL1W | 80.7 dB |
| Bl/√RE | 1.6 |
| Pmax | 9 W |
.jpg.webp)
PUNKTKILDE AUGFL2002-JN014 Ω | |
|---|---|
| 3″ Full-range | |
| fS | 80 Hz |
| SD | 28.8 cm² |
| 80 - 40000 Hz | |
| QTS | 0.51 |
| xmax | 1.3 mm |
| SPL1W | 83.1 dB |
| Bl/√RE | 1.55 |
| Pmax | 30 W |
.jpg.webp)
PUNKTKILDE AUGFL2001-JN014 Ω | |
|---|---|
| 2.5″ Full-range | |
| fS | 123 Hz |
| SD | 22.1 cm² |
| 120 - 40000 Hz | |
| QTS | 0.64 |
| xmax | 1.3 mm |
| SPL1W | 82.2 dB |
| Bl/√RE | 1.55 |
| Pmax | 20 W |
.jpg.webp)
PUNKTKILDE AUGFL0005-JN084 Ω | |
|---|---|
| 2″ Full-range | |
| fS | 144 Hz |
| SD | 15.2 cm² |
| 140 - 40000 Hz | |
| QTS | 0.48 |
| xmax | 1.3 mm |
| SPL1W | 82.3 dB |
| Bl/√RE | 1.59 |
| Pmax | 20 W |
.jpg.webp)
PUNKTKILDE AUGFL0001-JN014 Ω | |
|---|---|
| 1.5″ Full-range | |
| fS | 195 Hz |
| SD | 8.3 cm² |
| 200 - 40000 Hz | |
| QTS | 0.50 |
| xmax | 1.5 mm |
| SPL1W | 80.2 dB |
| Bl/√RE | 1.35 |
| Pmax | 10 W |
.jpg.webp)
PUNKTKILDE ASDFL1002-04014 Ω | |
|---|---|
| 2″ Full-range | |
| fS | 185 Hz |
| SD | 10.2 cm² |
| QTS | 0.49 |
| xmax | 1.5 mm |
| SPL1W | 80.2 dB |
| Bl/√RE | 1.95 |
| Pmax | 10 W |
