mivoc FR 358N Full-range
mivoc  FR 358N8 Ω
3.5″Full-range
fS
88 Hz
SD
36 cm²
80 - 20000 Hz
QTS
0.32
xmax
3.0 mm
SPL1W
89 dB
Bl/√RE
1.92
Pmax
80 W
accuton C90-6-724 Mid-range
accuton  C90-6-7248 Ω
5″Mid-range
fS
83 Hz
SD
81 cm²
QTS
0.60
xmax
3.0 mm
SPL1W
87 dB
Bl/√RE
2.55
Pmax
200 W
accuton C173-6-090 Mid-range
accuton  C173-6-0908 Ω
7″Mid-range
fS
72 Hz
SD
133 cm²
QTS
0.26
xmax
5.3 mm
SPL1W
92 dB
Bl/√RE
4.67
Pmax
240 W
accuton C168-6-990 Mid-range
accuton  C168-6-9908 Ω
6.5″Mid-range
fS
55 Hz
SD
133 cm²
QTS
0.21
xmax
3.0 mm
SPL1W
92 dB
Bl/√RE
5.02
Pmax
240 W
Wavecor WF120BD04/08 Mid-range
Wavecor  WF120BD04/088 Ω
4.75″Mid-range
fS
72 Hz
SD
54 cm²
71 - 4000 Hz
QTS
0.45
SPL1W
85 dB
Bl/√RE
2.25
Pmax
100 W
Wavecor WF120BD03/07 Mid-range
Wavecor  WF120BD03/074 Ω
4.75″Mid-range
fS
70 Hz
SD
54 cm²
70 - 4000 Hz
QTS
0.37
SPL1W
86 dB
Bl/√RE
2.52
Pmax
100 W
Wavecor WF090WA02 Mid-range
Wavecor  WF090WA028 Ω
3.5″Mid-range
fS
110 Hz
SD
36 cm²
110 - 5000 Hz
QTS
0.89
xmax
2.8 mm
SPL1W
84 dB
Bl/√RE
1.49
Pmax
15 W
Wavecor WF090WA01 Mid-range
Wavecor  WF090WA014 Ω
3.5″Mid-range
fS
109 Hz
SD
36 cm²
109 - 5000 Hz
QTS
0.76
xmax
2.8 mm
SPL1W
84 dB
Bl/√RE
1.65
Pmax
15 W
Wavecor SW070WA02 Mid-range
Wavecor  SW070WA028 Ω
2.75″Mid-range
fS
76 Hz
SD
22 cm²
76 - 4000 Hz
QTS
0.42
SPL1W
81 dB
Bl/√RE
1.88
Pmax
30 W
Wavecor SW070WA01 Mid-range
Wavecor  SW070WA014 Ω
2.75″Mid-range
fS
73 Hz
SD
22 cm²
73 - 4000 Hz
QTS
0.34
SPL1W
82 dB
Bl/√RE
2.15
Pmax
30 W
Wavecor FR090WA02 Mid-range
Wavecor  FR090WA028 Ω
3.5″Mid-range
fS
114 Hz
SD
36 cm²
114 - 20000 Hz
QTS
1.01
xmax
2.3 mm
SPL1W
84 dB
Bl/√RE
1.38
Pmax
20 W
Wavecor FR090WA01 Mid-range
Wavecor  FR090WA014 Ω
3.5″Mid-range
fS
113 Hz
SD
36 cm²
113 - 20000 Hz
QTS
0.85
xmax
2.3 mm
SPL1W
84 dB
Bl/√RE
1.54
Pmax
20 W
Wavecor FR084WA02 Mid-range
Wavecor  FR084WA028 Ω
3.5″Mid-range
fS
110 Hz
SD
36 cm²
110 - 20000 Hz
QTS
0.88
xmax
2.0 mm
SPL1W
84 dB
Bl/√RE
1.48
Pmax
20 W
Wavecor FR084WA01 Mid-range
Wavecor  FR084WA014 Ω
3.5″Mid-range
fS
109 Hz
SD
36 cm²
109 - 20000 Hz
QTS
0.79
xmax
2.0 mm
SPL1W
84 dB
Bl/√RE
1.6
Pmax
20 W
Wavecor FR070WA04 Mid-range
Wavecor  FR070WA048 Ω
2.75″Mid-range
fS
117 Hz
SD
21 cm²
117 - 20000 Hz
QTS
0.98
SPL1W
83 dB
Bl/√RE
1.15
Pmax
20 W
Wavecor FR070WA03 Mid-range
Wavecor  FR070WA034 Ω
2.75″Mid-range
fS
114 Hz
SD
21 cm²
114 - 20000 Hz
QTS
0.87
SPL1W
82 dB
Bl/√RE
1.24
Pmax
20 W
Wavecor FR070WA02 Mid-range
Wavecor  FR070WA028 Ω
2.75″Mid-range
fS
117 Hz
SD
21 cm²
117 - 20000 Hz
QTS
0.65
SPL1W
83 dB
Bl/√RE
1.42
Pmax
20 W
Wavecor FR070WA01 Mid-range
Wavecor  FR070WA014 Ω
2.75″Mid-range
fS
114 Hz
SD
21 cm²
114 - 20000 Hz
QTS
0.53
SPL1W
84 dB
Bl/√RE
1.62
Pmax
20 W
Wavecor FR055WA02 Mid-range
Wavecor  FR055WA028 Ω
2″Mid-range
fS
145 Hz
SD
16 cm²
145 - 20000 Hz
QTS
1.07
xmax
1.4 mm
SPL1W
82 dB
Bl/√RE
1.07
Pmax
20 W
Wavecor FR055WA01 Mid-range
Wavecor  FR055WA014 Ω
2″Mid-range
fS
142 Hz
SD
16 cm²
142 - 20000 Hz
QTS
0.91
xmax
1.4 mm
SPL1W
81 dB
Bl/√RE
1.19
Pmax
20 W
VISATON WS 13 E - 8 Ohm Full-range
VISATON  WS 13 E - 8 Ohm8 Ω
5″Full-range
fS
83 Hz
SD
87 cm²
83 - 12000 Hz
QTS
1.08
xmax
0.8 mm
SPL1W
88 dB
Bl/√RE
1.3
Pmax
60 W
VISATON SL 87 FE - 8 Ohm Full-range
VISATON  SL 87 FE - 8 Ohm8 Ω
3.4″Full-range
fS
120 Hz
SD
37 cm²
75 - 18000 Hz
QTS
0.65
xmax
1.8 mm
SPL1W
87 dB
Bl/√RE
1.47
Pmax
15 W
VISATON SL 713 - 4 Ohm Full-range
VISATON  SL 713 - 4 Ohm4 Ω
2.8 x 5″Full-range
fS
180 Hz
SD
50 cm²
100 - 20000 Hz
QTS
1.70
xmax
1.0 mm
SPL1W
93 dB
Bl/√RE
1.0
Pmax
15 W
VISATON SC 8 N - 8 Ohm Full-range
VISATON  SC 8 N - 8 Ohm8 Ω
3.3″Full-range
fS
110 Hz
SD
26 cm²
70 - 20000 Hz
QTS
0.97
xmax
0.5 mm
SPL1W
82 dB
Bl/√RE
0.907
Pmax
50 W
VISATON SC 5.9 - 8 Ohm Full-range
VISATON  SC 5.9 - 8 Ohm8 Ω
2 x 3.5″Full-range
fS
193 Hz
SD
27 cm²
130 - 20000 Hz
QTS
1.25
xmax
0.5 mm
SPL1W
89 dB
Bl/√RE
0.945
Pmax
15 W
VISATON SC 13 - 8 Ohm Mid Bass
VISATON  SC 13 - 8 Ohm8 Ω
5″Mid Bass
fS
78 Hz
SD
79 cm²
78 - 13000 Hz
QTS
0.71
xmax
0.8 mm
SPL1W
88 dB
Bl/√RE
1.57
Pmax
60 W
VISATON R 10 S TE - 8 Ohm Full-range
VISATON  R 10 S TE - 8 Ohm8 Ω
4″Full-range
fS
160 Hz
SD
56 cm²
100 - 13000 Hz
QTS
1.99
xmax
0.5 mm
SPL1W
93 dB
Bl/√RE
0.745
Pmax
30 W
VISATON R 10 SC - 8 Ohm Full-range
VISATON  R 10 SC - 8 Ohm8 Ω
4″Full-range
fS
165 Hz
SD
56 cm²
100 - 13000 Hz
QTS
1.76
xmax
0.5 mm
SPL1W
91 dB
Bl/√RE
0.882
Pmax
30 W
VISATON R 10 SC - 4 Ohm Full-range
VISATON  R 10 SC - 4 Ohm4 Ω
4″Full-range
fS
165 Hz
SD
56 cm²
100 - 13000 Hz
QTS
1.32
xmax
0.5 mm
SPL1W
92 dB
Bl/√RE
1.05
Pmax
30 W
VISATON R 10 S - 8 Ohm Full-range
VISATON  R 10 S - 8 Ohm8 Ω
4″Full-range
fS
160 Hz
SD
56 cm²
100 - 13000 Hz
QTS
1.99
xmax
0.5 mm
SPL1W
93 dB
Bl/√RE
0.745
Pmax
30 W
VISATON R 10 S - 4 Ohm Full-range
VISATON  R 10 S - 4 Ohm4 Ω
4″Full-range
fS
160 Hz
SD
56 cm²
100 - 13000 Hz
QTS
1.45
xmax
0.5 mm
SPL1W
93 dB
Bl/√RE
1.03
Pmax
30 W
VISATON HX 10 - 4 Ohm 2 Way
VISATON  HX 10 - 4 Ohm4 Ω
4″2 Way
fS
70 Hz
SD
55 cm²
50 - 22000 Hz
QTS
0.50
xmax
1.5 mm
SPL1W
87 dB
Bl/√RE
1.88
Pmax
60 W
VISATON FRS 8 M - 8 Ohm Full-range
VISATON  FRS 8 M - 8 Ohm8 Ω
3.3″Full-range
fS
125 Hz
SD
29 cm²
100 - 20000 Hz
QTS
0.49
SPL1W
87 dB
Bl/√RE
1.49
Pmax
50 W
VISATON FRS 8 - 8 Ohm Full-range
VISATON  FRS 8 - 8 Ohm8 Ω
3.3″Full-range
fS
120 Hz
SD
31 cm²
100 - 20000 Hz
QTS
1.04
xmax
0.5 mm
SPL1W
85 dB
Bl/√RE
1.19
Pmax
50 W
VISATON FRS 8 - 4 Ohm Full-range
VISATON  FRS 8 - 4 Ohm4 Ω
3.3″Full-range
fS
120 Hz
SD
31 cm²
100 - 20000 Hz
QTS
0.69
xmax
0.5 mm
SPL1W
84 dB
Bl/√RE
1.18
Pmax
50 W
VISATON FRS 7 W - 8 Ohm Full-range
VISATON  FRS 7 W - 8 Ohm8 Ω
2.5″Full-range
fS
160 Hz
SD
22 cm²
120 - 20000 Hz
QTS
0.63
xmax
1.0 mm
SPL1W
87 dB
Bl/√RE
0.973
Pmax
15 W
VISATON FRS 7 S - 8 Ohm Full-range
VISATON  FRS 7 S - 8 Ohm8 Ω
2.5″Full-range
fS
150 Hz
SD
22 cm²
120 - 20000 Hz
QTS
1.46
xmax
1.5 mm
SPL1W
88 dB
Bl/√RE
0.671
Pmax
15 W
VISATON FRS 5 XTS - 8 Ohm Full-range
VISATON  FRS 5 XTS - 8 Ohm8 Ω
2″Full-range
fS
190 Hz
SD
13 cm²
120 - 20000 Hz
QTS
0.70
SPL1W
84 dB
Bl/√RE
0.962
Pmax
8 W
VISATON FRS 5 X - 8 Ohm Full-range
VISATON  FRS 5 X - 8 Ohm8 Ω
2″Full-range
fS
190 Hz
SD
13 cm²
120 - 20000 Hz
QTS
0.70
SPL1W
84 dB
Bl/√RE
0.962
Pmax
8 W
VISATON FRS 10 WP - 8 Ohm Full-range
VISATON  FRS 10 WP - 8 Ohm8 Ω
4″Full-range
fS
190 Hz
SD
57 cm²
90 - 19000 Hz
QTS
0.98
xmax
1.0 mm
SPL1W
90 dB
Bl/√RE
1.7
Pmax
50 W
