4216 results
Nominal diameter
SensitivitySPL1W
dB

Thiele & Small parameters

Resonance frequencyfS
Hz
Mechanical quality factorQMS
Electrical quality factorQES
Total quality factorQTS

Large signal parameters

Maximum linear excursionxmax
mm
Air volume displaced at xmaxVD
cm³
Program powerPmax
W

Voice Coil & Magnet

Nominal impedanceZ
Ω
DC resistanceRE
Ω
Force factorBl
N/A
Motor constantBl/√RE
N/√W
InductanceLE
mH
VC Diameter
mm

Diaphragm

Effective diameter
mm
Effective areaSD
cm²
Moving massMMS
g

Suspensions

StiffnessKMS
N/mm
ComplianceCMS
µm/N
Equivalent volume to CMSVAS
L
Mechanical resistanceRMS
N·s/m

Dimensions

Overall size
mm
Baffle cutout diameter
mm
Overall depth
mm
Mounting depth
mm
Volume occupied
L
Net weight
kg
Wavecor WF275BD02 Mid Bass
10.75Mid Bass
fS
28 Hz
SD
312 cm²
28 - 1500 Hz
QTS
0.45
xmax
9.0 mm
SPL1W
88 dB
Bl/√RE
4.53
Pmax
450 W
Wavecor WF275BD01 Mid Bass
10.75Mid Bass
fS
27 Hz
SD
312 cm²
27 - 1500 Hz
QTS
0.37
xmax
9.0 mm
SPL1W
88 dB
Bl/√RE
5.05
Pmax
450 W
Wavecor WF182BD14/16 Mid Bass
7Mid Bass
fS
37 Hz
SD
117 cm²
37 - 2500 Hz
QTS
0.30
xmax
5.5 mm
SPL1W
87 dB
Bl/√RE
3.39
Pmax
250 W
Wavecor WF182BD13/15 Mid Bass
7Mid Bass
fS
36 Hz
SD
117 cm²
36 - 2500 Hz
QTS
0.25
xmax
5.5 mm
SPL1W
88 dB
Bl/√RE
3.8
Pmax
250 W
Wavecor WF166TU01 Woofer
6.5Woofer
fS
50 Hz
SD
139 cm²
50 - 3500 Hz
QTS
0.45
SPL1W
89 dB
Bl/√RE
2.91
Pmax
120 W
Wavecor WF165TU01 Mid Bass
5.5Mid Bass
fS
56 Hz
SD
136 cm²
56 - 3000 Hz
QTS
0.84
xmax
3.0 mm
SPL1W
86 dB
Bl/√RE
2.48
Pmax
170 W
Wavecor WF152BD10/12 Mid Bass
6Mid Bass
fS
46 Hz
SD
85 cm²
46 - 3000 Hz
QTS
0.38
xmax
4.5 mm
SPL1W
87 dB
Bl/√RE
2.92
Pmax
250 W
Wavecor WF152BD09/11 Mid Bass
6Mid Bass
fS
49 Hz
SD
85 cm²
49 - 3000 Hz
QTS
0.32
xmax
4.5 mm
SPL1W
87 dB
Bl/√RE
3.24
Pmax
250 W
Wavecor WF132TU01 Mid Bass
5.25Mid Bass
fS
60 Hz
SD
95 cm²
60 - 4000 Hz
QTS
0.43
SPL1W
88 dB
Bl/√RE
2.91
Pmax
110 W
Wavecor SW312TU02 Subwoofer
12.25Subwoofer
fS
28 Hz
SD
513 cm²
28 - 300 Hz
QTS
0.50
SPL1W
86 dB
Bl/√RE
7.99
Pmax
500 W
Wavecor SW280WA04 Subwoofer
11Subwoofer
fS
35 Hz
SD
321 cm²
35 - 300 Hz
QTS
0.54
xmax
6.0 mm
SPL1W
85 dB
Bl/√RE
6.22
Pmax
400 W
Wavecor SW280WA03 Subwoofer
11Subwoofer
fS
34 Hz
SD
321 cm²
34 - 300 Hz
QTS
0.45
xmax
6.0 mm
SPL1W
86 dB
Bl/√RE
6.88
Pmax
400 W
Wavecor FR4X6WA02 Full-range
1.75 x 2.5Full-range
fS
179 Hz
SD
15 cm²
179 - 20000 Hz
QTS
0.99
xmax
2.0 mm
SPL1W
82 dB
Bl/√RE
1.1
Pmax
15 W
Wavecor FR084WA03 Full-range
3.25Full-range
fS
116 Hz
SD
38 cm²
116 - 20000 Hz
QTS
1.78
xmax
2.5 mm
SPL1W
86 dB
Bl/√RE
0.971
Pmax
25 W
Wavecor FR070WA05 Full-range
2.75Full-range
fS
89 Hz
SD
22 cm²
89 - 20000 Hz
QTS
0.47
xmax
2.7 mm
SPL1W
81 dB
Bl/√RE
2.04
Pmax
15 W
Wavecor FR055WA05 Full-range
2Full-range
fS
135 Hz
SD
16 cm²
135 - 20000 Hz
QTS
1.67
xmax
1.4 mm
SPL1W
83 dB
Bl/√RE
0.752
Pmax
20 W
Wavecor FR055WA04 Full-range
2Full-range
fS
131 Hz
SD
16 cm²
131 - 20000 Hz
QTS
0.66
xmax
1.4 mm
SPL1W
82 dB
Bl/√RE
1.33
Pmax
20 W
Wavecor FR055WA03 Full-range
2Full-range
fS
128 Hz
SD
16 cm²
128 - 20000 Hz
QTS
0.51
xmax
1.4 mm
SPL1W
83 dB
Bl/√RE
1.53
Pmax
20 W
Wavecor FR4X6WA01 Full-range
1.75 x 2.5Full-range
fS
173 Hz
SD
15 cm²
173 - 20000 Hz
QTS
0.86
xmax
2.0 mm
SPL1W
82 dB
Bl/√RE
1.21
Pmax
15 W
PHL audio HP3860NdM Mid-range
10Mid-range
fS
90 Hz
SD
377 cm²
120 - 3000 Hz
QTS
0.23
xmax
2.5 mm
SPL1W
98 dB
Bl/√RE
9.25
Pmax
500 W
PHL audio HP3860 Mid-range
10Mid-range
fS
90 Hz
SD
377 cm²
120 - 3000 Hz
QTS
0.24
xmax
2.5 mm
SPL1W
98 dB
Bl/√RE
9.0
Pmax
500 W
PHL audio HP2460 Mid Bass
8Mid Bass
fS
79 Hz
SD
219 cm²
80 - 4000 Hz
QTS
0.45
xmax
5.5 mm
SPL1W
93 dB
Bl/√RE
4.56
Pmax
320 W
PHL audio 982Nd Coaxial
5Coaxial
fS
130 Hz
SD
96 cm²
110 - 16000 Hz
QTS
0.45
xmax
4.5 mm
SPL1W
92 dB
Bl/√RE
3.69
Pmax
200 W
PHL audio 982 Coaxial
5Coaxial
fS
130 Hz
SD
96 cm²
110 - 16000 Hz
QTS
0.46
xmax
4.5 mm
SPL1W
92 dB
Bl/√RE
3.64
Pmax
200 W
PHL audio 973Nd Coaxial
5Coaxial
fS
67 Hz
SD
92 cm²
60 - 3000 Hz
QTS
0.39
xmax
6.5 mm
SPL1W
88 dB
Bl/√RE
3.23
Pmax
240 W
PHL audio 973 Coaxial
5Coaxial
fS
67 Hz
SD
92 cm²
60 - 3000 Hz
QTS
0.40
xmax
6.5 mm
SPL1W
88 dB
Bl/√RE
3.18
Pmax
240 W
PHL audio 970Nd Coaxial
5Coaxial
fS
67 Hz
SD
92 cm²
60 - 16000 Hz
QTS
0.35
xmax
6.5 mm
SPL1W
89 dB
Bl/√RE
3.39
Pmax
240 W
PHL audio 970 Coaxial
5Coaxial
fS
67 Hz
SD
92 cm²
60 - 16000 Hz
QTS
0.36
xmax
6.5 mm
SPL1W
88 dB
Bl/√RE
3.35
Pmax
240 W
PHL audio 950Nd Mid-range
5Mid-range
fS
200 Hz
SD
109 cm²
300 - 4000 Hz
QTS
0.59
xmax
2.0 mm
SPL1W
94 dB
Bl/√RE
3.94
Pmax
160 W
PHL audio 950 Mid-range
5Mid-range
fS
200 Hz
SD
109 cm²
300 - 4000 Hz
QTS
0.62
xmax
2.0 mm
SPL1W
94 dB
Bl/√RE
3.82
Pmax
160 W
PHL audio 930Nd Mid Bass
5Mid Bass
fS
129 Hz
SD
106 cm²
110 - 4000 Hz
QTS
0.48
xmax
4.5 mm
SPL1W
92 dB
Bl/√RE
3.69
Pmax
200 W
PHL audio 930 Mid Bass
5Mid Bass
fS
130 Hz
SD
106 cm²
110 - 4000 Hz
QTS
0.50
xmax
4.5 mm
SPL1W
92 dB
Bl/√RE
3.64
Pmax
200 W
PHL audio 900Nd Mid Bass
5Mid Bass
fS
65 Hz
SD
102 cm²
60 - 3000 Hz
QTS
0.36
xmax
6.5 mm
SPL1W
89 dB
Bl/√RE
3.39
Pmax
240 W
PHL audio 7321Nd Subwoofer
18Subwoofer
fS
34 Hz
SD
1250 cm²
25 - 800 Hz
QTS
0.28
xmax
10.0 mm
SPL1W
96 dB
Bl/√RE
12
Pmax
2400 W
PHL audio 7221Nd Subwoofer
18Subwoofer
fS
34 Hz
SD
1250 cm²
25 - 800 Hz
QTS
0.29
xmax
10.0 mm
SPL1W
96 dB
Bl/√RE
12
Pmax
2000 W
PHL audio 7081 Subwoofer
18Subwoofer
fS
34 Hz
SD
1282 cm²
30 - 800 Hz
QTS
0.41
xmax
7.5 mm
SPL1W
95 dB
Bl/√RE
9.59
Pmax
1500 W
PHL audio 6301MNd Subwoofer
15Subwoofer
fS
36 Hz
SD
871 cm²
30 - 1000 Hz
QTS
0.26
xmax
10.5 mm
SPL1W
95 dB
Bl/√RE
11
Pmax
2600 W
PHL audio 6201MNd Subwoofer
15Subwoofer
fS
36 Hz
SD
871 cm²
30 - 1000 Hz
QTS
0.27
xmax
10.5 mm
SPL1W
95 dB
Bl/√RE
11
Pmax
2000 W
PHL audio 6121M-20 Coaxial
15Coaxial
fS
39 Hz
SD
892 cm²
35 - 1000 Hz
QTS
0.24
xmax
8.5 mm
SPL1W
96 dB
Bl/√RE
12
Pmax
1600 W
PHL audio 6031M Subwoofer
15Subwoofer
fS
39 Hz
SD
892 cm²
35 - 1000 Hz
QTS
0.23
xmax
8.5 mm
SPL1W
96 dB
Bl/√RE
12
Pmax
2000 W
